Heterogeneous memory systems are becoming more prominent in high performance computing (HPC) with the introduction of High Bandwidth Memory (HBM) and Non-Volatile Memory (NVM) technologies. All these memory technologies along with DRAM, while being byte-addressable, have different latency, bandwidth, power and persistence characteristics that they bring to the table. NVM adds to the capacity of main memory and expands the address space of applications but lowers access speeds. HBM provides higher memory access bandwidth but has lower density than DRAM. Although there is software support for using all the above memory technologies in their individual capacity, there is a lack of runtime support that takes advantage of all the benefits of a heterogeneous memory system while being as user-transparent as possible. To this end, we present a memory-aware runtime system and programming paradigm called PEARS that enables HPC application programmers to write traditional HPC workloads while taking advantage of multiple benefits of a byte-addressable, heterogeneous memory system. We demonstrate PEARS abstractions for workloads of matrix-multiplication and a variety of stencils with different dimensionality while comparing performance to the standard baseline implementations of these workloads under various memory allocation scenarios.

Non-Volatile Memory (NVM) is a byte-addressable, high capacity, high latency and a persistent form of memory that can extend the primary memory hierarchy by another level. It is up to 8x denser than DRAM, allowing for clusters with compute nodes that have significantly higher memory capacity than those of previous generations. Intel’s Optane DC Persistent Memory Module (PMM) is such an NVM device that can be used to increase the memory density of high performance computing (HPC) systems. This work hypothesizes that with highermemory density, scientific computing applications with larger problem sizes can be run on fewer compute nodes than on current HPC systems. This, in turn, can reduce operational cost. This work tests this hypothesis by comparing performance and energy of HPC jobs with large problem sizes of (1) fewer nodes with large NVM capacity under various configurations and (2) more nodes with an equivalent amount of DRAM memory. In experiments, performance and energy consumption are shown to be dependent on application characteristics: Codes optimized for high cache reuse suffer no performance degradation on NVM, combined with significant energy savings at lower acquisition and operational costs compared to traditional HPC systems without NVM. In contrast, memory bound applications using DRAM as a cache for NVMmay provide a small performance benefit over using a DRAM-NVM hybrid memory.

The Dragonfly network organizes routers into groups, with connectivity within each group provided by local links and connectivity between groups provided by global links. The specification of Dragonfly leaves many options for arranging global links. In this work, we study global link arrangement for practical Dragonfly topologies where (1) there are multiple global links connecting each pair of groups, and (2) the global link bandwidth is similar to the local link bandwidth. We found that existing global link arrangement schemes such as the absolute, relative and circulant-based arrangements do not specify an important component in global connectivity for practical Dragonfly, which we call per-router arrangement. Per-router arrangement determines how the global links from each individual router are connected. We integrate per-router arrangement into existing schemes, develop a unified algorithm to compute a large class of global link arrangements for practical Dragonfly, and carry out an extensive simulation study to evaluate different global link arrangement schemes. Our results indicate that the existing understanding of the global link arrangement does not apply to practical Dragonfly: contradict to the existing understanding that global link arrangement does not make significant difference in performance when global links have similar bandwidth as local links, per-router arrangement significantly impacts the network performance of practical Dragonfly. We identify the schemes that yield high performance for practical Dragonfly.

The introduction of NVDIMM memory devices has encouraged the use of DRAM/NVM based hybrid memory systems to increase the memory-per-core ratio in compute nodes and obtain possible energy and cost benefits. However, Non-Volatile Memory (NVM) is slower than DRAM in terms of read/write latency. This difference in performance will adversely affect memory-bound applications. Traditionally, data prefetching at the hardware level has been used to increase the number of cache hits to mitigate performance degradation. However, software (SW) prefetching has not been used effectively to reduce the effects of high memory access latencies. Also, the current cache hierarchy and hardware (HW) prefetching are not optimized for a hybrid memory system. We hypothesize that HW and SW prefetching can complement each other in placing data in caches and the Data Translation Look-aside Buffer (DTLB) prior to their references, and by doing so adaptively, highly varying access latencies in a DRAM/NVM hybrid memory system are taken into account. This work contributes an adaptive SW prefetch method based on the characterization of read/write/unroll prefetch distances for NVM and DRAM. Prefetch performance is characterized via custom benchmarks based on STREAM2 specifications in a multicore MPI runtime environment and compared to the performance of the standard SW prefetch pass in GCC. Furthermore, the effects of HW prefetching on kernels executing on hybrid memory system are evaluated. Experimental results indicate that SW prefetching targeted to populate the DTLB results in up to 26% performance improvement when symbiotically used in conjunction with HW prefetching, as opposed to only HW prefetching. Based on our findings, changes to GCC's prefetch-loop-arrays compiler pass are proposed to take advantage of DTLB prefetching in a hybrid memory system for kernels that are frequently used in HPC applications.

The traditional parallel programming models require programmers to explicitly specify parallelism and data movement of the underlying parallel mechanisms. Different from the traditional computation-centric programming, Legion provides a data-centric programming model for extracting parallelism and data movement. In this chapter, we aim to characterize the power and energy consumption of running HPC applications on Legion. We run benchmark applications on compute nodes equipped with both CPU and GPU, and measure the execution time, power consumption and CPU/GPU utilization. Additionally, we test the message passing interface (MPI) version of these applications and compare the performance and power consumption of high-performance computing (HPC) applications using the computation-centric and data-centric programming models. Experimental results indicate Legion applications outperforms MPI applications on both performance and energy efficiency, i.e., Legion applications can be 9.17 times as fast as MPI applications and use only 9.2% energy. Legion effectively explores the heterogeneous architecture and runs applications tasks on GPU. As far as we know, this is the first study to understand the power and energy consumption of Legion programming and runtime infrastructure. Our findings will enable HPC system designers and operators to develop and tune the performance of data-centric HPC applications with constraints on power and energy consumption.

System logs provide invaluable resources for understanding system behavior and detecting anomalies on high performance computing (HPC) systems. As HPC systems continue to grow in both scale and complexity, the sheer volume of system logs and the complex interaction among system components make the traditional manual problem diagnosis and even automated line-by-line log analysis infeasible or ineffective. Sequence mining technologies aim to identify important patterns among a set of objects, which can help us discover regularity among events, detect anomalies, and predict events in HPC environments. The existing sequence mining algorithms are compute-intensive and inefficient to process the overwhelming number of system events which have complex interaction and dependency. In this paper, we present a novel, topology-aware sequence mining method (named TSM) and explore it for event analysis and anomaly detection on production HPC systems. TSM is resource-efficient and capable of producing long and complex event patterns from log messages, which makes TSM suitable for online monitoring and diagnosing of large-scale systems. We evaluate the performance of TSM using system logs collected from a production supercomputer. Experimental results show that TSM is highly efficient in identifying event sequences on single and multiple nodes without any prior knowledge. We apply verification functions and requirements and prove the correctness of the event patterns produced by TSM.

decisions left to the caller. Second, a high-level, policy-based interface designed for ease of use for the application developer, in which we aim for best-practice decisions based on application intent. We have developed such a library, called SICM: Simplified Interface to Complex Memory.

The Dragonfly network has been deployed in the current generation supercomputers and will be used in the next generation supercomputers. The Universal Globally Adaptive Load-balance routing (UGAL) is the state-of-the-art routing scheme for Dragonfly. In this work, we show that the performance of the conventional UGAL can be further improved on many practical Dragonfly networks, especially the ones with a small number of groups, by customizing the paths used in UGAL for each topology. We develop a scheme to compute the custom sets of paths for each topology and compare the performance of our topology-custom UGAL routing (T-UGAL) with conventional UGAL. Our evaluation with different UGAL variations and different topologies demonstrates that by customizing the routes, T-UGAL offers significant improvements over UGAL on many practical Dragonfly networks in terms of both latency when the network is under low load and throughput when the network is under high load.

Non-volatile, byte-addressable memory (NVM) has been introduced by Intel in the form of NVDIMMs named Intel® Optane™ DC PMM. This memory module has the ability to persist the data stored in it without the need for power. This expands the memory hierarchy into a hybrid memory system due the differences in access latency and memory bandwidth from DRAM, which has been the predominant byte-addressable main memory technology. The Optane DC memory modules have up to 8x the capacity of DDR4 DRAM modules which can expand the byte-address space up to 6 TB per node. Many applications can now scale up the their problem size given such a memory system. We evaluate the capabilities of this DRAM-NVM hybrid memory system and its impact on High Performance Computing (HPC) applications. We characterize the Optane DC in comparison to DDR4 DRAM with a STREAM-like custom benchmark and measure the performance for HPC mini-apps like VPIC, SNAP, LULESH and AMG under different configurations of Optane DC PMMs. We find that Optane-only executions are slower in terms of execution time than DRAM-only and Memory-mode executions by a minimum of 2 to 16% for VPIC and maximum of 6x for LULESH.

With the increasing complexity of memory and storage, it is important to automate the decision of how to assign data structures to memory and storage devices. On one hand, this requires developing models to reconcile application access patterns against the limited capacity of higher-performance devices. On the other, such a modeling task demands a set of primitives to build from, and a toolkit that implements those primitives in a robust, dynamic fashion. We focus on the latter problem, and to that end we present an interface that abstracts the physical layout of data from the application developer. This will allow developers focused on optimized data placement to use our abstracta as the basis for their implementation, while application developers will see a unified, scalable, and resilient memory environment.

Universal globally adaptive load-balanced (UGAL) routing has been proposed for various interconnection networks and has been deployed in a number of current-generation supercomputers. Although UGAL-based schemes have been extensively studied, most existing results are based on either simulation or measurement. Without a theoretical understanding of UGAL, multiple questions remain: For which traffic patterns is UGAL most suited? In addition, what determines the performance of the UGAL-based scheme on a particular network configuration? In this work, we develop a set of throughput models for UGALbased on linear programming. We show that the throughput models are valid across the torus, Dragonfly, and Slim Fly network topologies. Finally, we identify a robust model that can accurately and efficiently predict UGAL throughput for a set of representative traffic patterns across different topologies. Our models not only provide a mechanism to predict UGAL performance on large-scale interconnection networks but also reveal the inner working of UGAL and further our understanding of this type of routing.

System logs provide invaluable resources for understanding system behavior and detecting anomalies on high performance computing (HPC) systems. As HPC systems continue to grow in both scale and complexity, the sheer volume of system logs and the complex interaction among system components make the traditional manual problem diagnosis and even automated line-by-line log analysis infeasible or ineffective. In this paper, we present a System Log Event Block Detection (SLEBD) framework that identifies groups of log messages that follow certain sequence but with variations, and explore these event blocks for event-based system behavior analysis and anomaly detection. Compared with the existing approaches that analyze system logs line by line, SLEBD is capable of characterizing system behavior and identifying intricate anomalies at a higher (i.e., event) level. We evaluate the performance of SLEBD by using syslogs collected from production supercomputers. Experimental results show that our framework and mechanisms can process streaming log messages, efficiently extract event blocks and effectively detect anomalies, which enables system administrators and monitoring tools to understand and process system events in real time. Additionally, we use the identified event blocks and explore deep learning algorithms to model and classify event sequences.

Beckinsale (LLNL), Paolo Faraboschi (HPE

Storage systems are indispensable for big data processing and cloud computing services today. The ever-growing size of computation and data analytic results demands larger storage capacity, which challenges data processing and storage scalability. Moreover, the increasing complexity of storage hierarchy and "passive" storage devices make todays storage systems inefficient, which necessitates the adoption of new storage technologies. In this paper, we explore new Ethernet connected drives with on-drive embedded CPU and DRAM to develop an active cloud storage system where data can be processed on disk drives without data movement. These drives are micro-storage servers that can support software-defined storage. In addition to I/O operations, we test and evaluate on-drive data processing, including data compression, aggregation and erasure encoding, which provide natural support for data-intensive applications. Our experimental results show that Open Ethernet Drive can significantly lower the energy consumption while maintaining the data processing throughput simultaneously by ensuring data availability and storage scalability. Results and findings from this work will facilitate scheduling of on-drive compute resource for building active and scalable cloud storage systems.

Nonuniform Memory Access (NUMA) will likely continue to be the chief abstraction used to expose heterogeneous memory. One major problem with using NUMA in this way is, the assignment of memory to devices, mediated by the hardware and Linux OS, is only resolved to page granularity. That is, pages, not allocations, are explicitly assigned to memory devices. This is particularly troublesome if one wants to migrate data between devices: since only pages can be migrated, other data allocated on the same pages will be migrated as well, and it isn't easy to tell what data will be swept along to the target device. We propose a solution to this problem based on repurposing arena-based heap management to keep locality among related data structures that are used together, and discuss our work on such a heap manager.

Power efficiency nowadays is a mainstream pressing issue in High Performance Computing (HPC), due to limited power supply capability of current and projected supercomputers. As a promising solution, leveraging inherent application resilience to relax power requirements of HPC runs can effectively save power with minor/acceptable loss of output quality. However, the challenges of this approach lie in: (a) how to reduce power usage of HPC runs online within allowable maximum extent such that quality metrics of applications can be satisfied, and (b) how to identify potential intrinsic nature of fault tolerance in general for an application. Existing efforts to date fail to address both challenges systematically and efficiently. In this work, based on virtualization and near-threshold voltage reduction techniques, we propose an empirical framework named V-Power to save the most power for inherently resilient applications. As an integrated empirical system, our approach effectively addresses the two above challenges using quantitative and fine-grained application inherent resilience analysis and frequency-independent near-threshold voltage reduction. Experimental results for a wide spectrum of scientific applications running on a 40-core power-aware server demonstrate that V-Power is capable of saving power up to 12.3%, resulting in a failure rate with acceptable program outputs. (C) 2017 Elsevier B.V. All rights reserved.

We present a novel trace-based analysis tool that rapidly classifies an MPI application as bandwidth-bound, latency-bound, load-imbalance-bound, or computation-bound for different interconnection networks. The tool uses an extension of Lamport's logical clock to track application progress in the trace replay. It has two unique features. First, it predicts application performance for many latency and bandwidth parameters from a single replay of the trace. Second, it infers the performance characteristics of an application and classifies the application using the predicted performance trend for a range of network configurations instead of using the predicted performance for a particular network configuration. We describe the techniques used in the tool and its design and implementation, and report our performance study of the tool and our experience with classifying nine applications and mini-apps from the DOE Design Forward project as well as the NAS Parallel Benchmarks.

High Performance Computing (HPC) applications and systems are often studied through modeling and simulation at various granularities. As the size of HPC systems and applications and the cost of high fidelity simulation continue to grow, a good understanding of the trade-offs of the complexity and accuracy of HPC application modeling and simulation schemes can help balance the competing goals of accuracy and time. In this work, we investigate the complexity and accuracy trade-off using an MPI application modeling tool and an MPI application simulation tool. The performance and accuracy results of modeling and simulation of a large spectrum of HPC applications on three supercomputers are measured and compared. The results show that although modeling is often one to two orders of magnitude faster than simulation, it achieves within 5% of predicted application time in comparison to simulation for 85% of cases in our data set. We further enhance the modeling tool with a statistical model to predict whether simulation can yield significantly different results than modeling. The enhanced tool achieves a very high successful prediction rate of 93.2% on our dataset and is thus effective in determining whether modeling or simulation should be used.

Providing a software environment that can overcome the complexities of changes in how future supercomputers will be designed plays a key role in improving the nation’s rate of scientific discovery and innovation. In the past three decades, advances in computer technology have allowed the performance and functionality of processors to double every 2 years. This trend, known as Moore’s Law, has enabled both computational and experimental science to leverage the so far unending growth of the broad computing industry with very little change to the supporting software environment. But as computer chip manufacturing techniques reach the limits of the atomic scale, this era of predictable improvements is ending. This shift will have a significant impact on the design of high-performance computers, as well as the established software infrastructure required to effectively utilize the nation’s Leadership Computing Facilities. Computer vendors are pursuing systems built from combinations of different types of processors to improve capabilities, boost performance, and meet energy efficiency goals. Some of the most current supercomputers do not rely on a single type of processor but instead have added computational accelerators to meet the growing demands of increasingly complex computational workloads. According to studies from the US Department of Energy (DOE) Office of Science Advanced Scientific Computing Research program, several types of special-purpose accelerated processing units are currently under development and will play a huge role in the future of computer architectures. It is also likely that these processors will be augmented with diverse types of memory and data storage capabilities. These significant changes are driven by extreme growth in the data-centric machine learning and artificial intelligence marketplaces that far exceed the revenues represented by high-performance computing for computational and experimental science. In the 2025–2030 time frame, external economic drivers and design diversity will result in systems built from a custom aggregation of components; and the difficulty and complexity of developing scientific software will increase. This fundamental change in computer architecture design has been deemed the era of “extreme heterogeneity.” The 2018 Basic Research Needs Workshop on Extreme Heterogeneity identified five Priority Research Directions for realizing the capabilities needed to address the challenges posed in this era of rapid technological change.

The Random regular graph (RRG) has recently been proposed as an interconnect topology for future large scale data centers and HPC clusters. An RRG is a special case of directed regular graph (DRG) where each link is unidirectional and all nodes have the same number of incoming and outgoing links. In this work, we establish bounds for DRGs on diameter, average $k$ -shortest path length, and a load balancing property with $k$ -shortest path routing, and use these bounds to evaluate RRGs. The results indicate that an RRG with $k$ -shortest path routing is not ideal in terms of diameter and load balancing. We further consider the Generalized De Bruijn Graph (GDBG), a deterministic DRG, and prove that for most network configurations, a GDBG is near optimal in terms of diameter, average $k$ -shortest path length, and load balancing with a $k$ -shortest path routing scheme. Finally, we use modeling and simulation to exploit the strengths and weaknesses of RRGs for different traffic conditions by comparing RRGs with GDBGs.
