Computing derivatives of path integrals under evolving scene geometry is a fundamental problem in physics-based differentiable rendering, which requires differentiating discontinuities in the visibility function. Warped-area reparameterization is a powerful technique to compute differential visibility, and key is construction of a velocity field that is continuous in the domain interior and agrees with defined velocities on boundaries. Robustly and efficiently constructing such fields remains challenging. We present a novel velocity field construction for differential visibility. Inspired by recent Monte Carlo solvers for partial differential equations (PDEs), we formulate the velocity field via Laplace's equation and solve it with a walk-on-spheres (WoS) algorithm. To improve efficiency, we introduce a fixed-step WoS that terminates random walks after a fixed step count, resulting in a continuous but non-harmonic velocity field still valid for warped-area reparameterization. Furthermore, to practically apply our method to complex 3D scenes, we propose an efficient cone query to find the closest silhouettes on a boundary. Our cone query finds the closest point under the geodesic distance on a unit sphere, and is analogous to the closest point query by WoS to compute Euclidean distance. As a result, our method generalizes WoS to perform random walks on spherical caps over the unit sphere. We demonstrate that this enables a more robust and efficient unbiased estimator for differential

The past five years has seen rapid growth in techniques that replace physically based shading algorithms with learned neural approximations. These techniques compress data and code to provide compact, high-quality approximations to complex algorithms. As of recently, these algorithms can now be hardware accelerated using cross-platform APIs in Vulkan and Direct3D to access AI acceleration hardware. Combined with modern differentiable shading languages, there is now a complete development toolchain for building and deploying neural shaders. The course will take attendees on a theory-to-practice journey through the neural shading space, starting with a survey of the types of techniques and their applications. We will then teach the math behind neural shading, starting small and adding detail from there. After that, the course will cover hardware acceleration concepts and share tips on bringing models from training into a production C++ environment. We close by reviewing a few "full" neural graphics models and discuss how they advance the state-of-the-art in real-time graphics. After completing this course, participants will understand neural shading fundamentals, and be able to build and deploy hardware-accelerated neural shading models in modern renderers.

We present a complete system for real-time rendering of scenes with complex appearance previously reserved for offline use. This is achieved with a combination of algorithmic and system level innovations. Our appearance model utilizes learned hierarchical textures that are interpreted using neural decoders, which produce reflectance values and importance-sampled directions. To best utilize the modeling capacity of the decoders, we equip the decoders with two graphics priors. The first prior -- transformation of directions into learned shading frames -- facilitates accurate reconstruction of mesoscale effects. The second prior -- a microfacet sampling distribution -- allows the neural decoder to perform importance sampling efficiently. The resulting appearance model supports anisotropic sampling and level-of-detail rendering, and allows baking deeply layered material graphs into a compact unified neural representation. By exposing hardware accelerated tensor operations to ray tracing shaders, we show that it is possible to inline and execute the neural decoders efficiently inside a real-time path tracer. We analyze scalability with increasing number of neural materials and propose to improve performance using code optimized for coherent and divergent execution. Our neural material shaders can be over an order of magnitude faster than non-neural layered materials. This opens up the door for using film-quality visuals in real-time applications such as games and live previews.

We introduce SLANG.D, an extension to the Slang shading language that incorporates first-class automatic differentiation support. The new shading language allows us to transform a Direct3D-based path tracer to be fully differentiable with minor modifications to existing code. SLANG.D enables a shared ecosystem between machine learning frameworks and pre-existing graphics hardware API-based rendering systems, promoting the interchange of components and ideas across these two domains. Our contributions include a differentiable type system designed to ensure type safety and semantic clarity in codebases that blend differentiable and non-differentiable code, language primitives that automatically generate both forward and reverse gradient propagation methods, and a compiler architecture that generates efficient derivative propagation shader code for graphics pipelines. Our compiler supports differentiating code that involves arbitrary control-flow, dynamic dispatch, generics and higher-order differentiation, while providing developers flexible control of checkpointing and gradient aggregation strategies for best performance. Our system allows us to differentiate an existing real-time path tracer, Falcor, with minimal change to its shader code. We show that the compiler-generated derivative kernels perform as efficiently as handwritten ones. In several benchmarks, the SLANG.D code achieves significant speedup when compared to prior automatic differentiation systems.

The continuous advancement of photorealism in rendering is accompanied by a growth in texture data and, consequently, increasing storage and memory demands. To address this issue, we propose a novel neural compression technique specifically designed for material textures. We unlock two more levels of detail, i.e., 16x more texels, using low bitrate compression, with image quality that is better than advanced image compression techniques, such as AVIF and JPEG XL. At the same time, our method allows on-demand, real-time decompression with random access similar to block texture compression on GPUs, enabling compression on disk and memory. The key idea behind our approach is compressing multiple material textures and their mipmap chains together, and using a small neural network, that is optimized for each material, to decompress them. Finally, we use a custom training implementation to achieve practical compression speeds, whose performance surpasses that of general frameworks, like PyTorch, by an order of magnitude.

Despite recent advances in Monte Carlo path tracing at interactive rates, denoised image sequences generated with few samples per-pixel often yield temporally unstable results and loss of high-frequency details. We present a novel adaptive rendering method that increases temporal stability and image fidelity of low sample count path tracing by distributing samples via spatio-temporal joint optimization of sampling and denoising. Adding temporal optimization to the sample predictor enables it to learn spatio-temporal sampling strategies such as placing more samples in disoccluded regions, tracking specular highlights, etc; adding temporal feedback to the denoiser boosts the effective input sample count and increases temporal stability. The temporal approach also allows us to remove the initial uniform sampling step typically present in adaptive sampling algorithms. The sample predictor and denoiser are deep neural networks that we co-train end-to-end over multiple consecutive frames. Our approach is scalable, allowing trade-off between quality and performance, and runs at near real-time rates while achieving significantly better image quality and temporal stability than previous methods.

A method, computer readable medium, and system are disclosed for computing a path for a user to move along within a physical space while viewing a virtual environment in a virtual reality system. A path for a user to physically move along through a virtual environment is determined based on waypoints and at least one characteristic of the physical environment within which the user is positioned, position data for the user is received indicating whether and how much a current path taken by the user has deviated from the path, and an updated path is computed through the virtual environment based on the waypoints and the at least one characteristic of the physical environment.

Efficiently rendering direct lighting from millions of dynamic light sources using Monte Carlo integration remains a challenging problem, even for off-line rendering systems. We introduce a new algorithm---ReSTIR---that renders such lighting interactively, at high quality, and without needing to maintain complex data structures. We repeatedly resample a set of candidate light samples and apply further spatial and temporal resampling to leverage information from relevant nearby samples. We derive an unbiased Monte Carlo estimator for this approach, and show that it achieves equal-error 6×-60× faster than state-of-the-art methods. A biased estimator reduces noise further and is 35×-65× faster, at the cost of some energy loss. We implemented our approach on the GPU, rendering complex scenes containing up to 3.4 million dynamic, emissive triangles in under 50 ms per frame while tracing at most 8 rays per pixel.

Convolutional neural networks have been shown to be a powerful tool for reducing the variance of Monte Carlo rendering techniques. Unfortunately in the low sample count regimes of real-time and interactive rendering, current CNN based denoisers cannot provide acceptable quality or temporal stability. Rather than relying on new network architectures or loss functions, this work improves the quality of existing architectures by continuously re-training the model to the current on-screen content. During inference, the renderer provides additional samples as supervision for the network, which allows the model’s capacity to be specialized beyond the original set of fixed weights. Additionally, the run-time overhead is minimized with Noise2Noise techniques that limit the number of extra samples needed from the renderer. The flexibility of this strategy allows training cost to be adjusted across several different axes, for a controllable tradeoff between quality improvement and performance.

A method, computer readable medium, and system are disclosed for performing spatiotemporal filtering. The method includes identifying image data to be rendered, reconstructing the image data to create reconstructed image data, utilizing a filter including a neural network having one or more skip connections and one or more recurrent layers, and returning the reconstructed image data.

In this short paper we present a machine learning approach to detect visual artifacts in rendered image sequences. Specifically, we train a deep neural network using example aliased and antialiased image sequences exported from a real-time renderer. The trained network learns to identify and locate aliasing artifacts in an input sequence, without comparing it against a ground truth. Thus, it is useful as a fully automated tool for evaluating image quality. We demonstrate the effectiveness of our approach in detecting aliasing in several rendered sequences. The trained network correctly predicts aliasing in 64 x 64 x 4 animated sequences with more than 90% accuracy for images it hasn't seen before. The output of our network is a single scalar between 0 and 1, which is usable as a quality metric for aliasing. It follows the same trend as (1-SSIM) for images with increasing sample counts.

Ein Verfahren, ein computerlesbares Medium und ein System werden zum Durchfuhren einer raumlich-zeitlichen Filterung offenbart. Das Verfahren umfasst Kennzeichnen von zu rendernden Bilddaten, Rekonstruieren der Bilddaten, um rekonstruierte Bilddaten zu erzeugen, Benutzung eines Filters, das ein neurales Netzwerk umfasst, das eine oder mehrere Ubersprungverbindungen und eine oder mehrere rekurrente Schichten aufweist, und Zuruckgeben der rekonstruierten Bilddaten.

Geometric aliasing is a persistent challenge for real-time rendering. Hardware multisampling remains limited to 8x, analytic coverage fails to capture correlated visibility samples, and spatial and temporal postfiltering primarily target edges of superpixel primitives. We describe a novel semi-analytic representation of coverage designed to make progress on geometric antialiasing for subpixel primitives and pixels containing many edges while handling correlated subpixel coverage. Although not yet fast enough to deploy, it crosses three critical thresholds: image quality comparable to 256x MSAA, faster than 64x MSAA, and constant space per pixel.

A method, computer readable medium, and system are disclosed for rendering shadows. A frustum projected from a grid cell corresponding to a light source in light-space is defined and a graphics primitive is determined to intersect the frustum. A light-space visibility buffer is accessed to obtain a set of pixel fragment footprints corresponding to the frustum and it is identified whether each pixel fragment footprint of the pixel fragment footprints is shadowed by the graphics primitive.

We describe a machine learning technique for reconstructing image sequences rendered using Monte Carlo methods. Our primary focus is on reconstruction of global illumination with extremely low sampling budgets at interactive rates. Motivated by recent advances in image restoration with deep convolutional networks, we propose a variant of these networks better suited to the class of noise present in Monte Carlo rendering. We allow for much larger pixel neighborhoods to be taken into account, while also improving execution speed by an order of magnitude. Our primary contribution is the addition of recurrent connections to the network in order to drastically improve temporal stability for sequences of sparsely sampled input images. Our method also has the desirable property of automatically modeling relationships based on auxiliary per-pixel input channels, such as depth and normals. We show significantly higher quality results compared to existing methods that run at comparable speeds, and furthermore argue a clear path for making our method run at realtime rates in the near future.

Interactive ray tracing applications running on commodity hardware can suffer from objectionable temporal artifacts due to a low sample count. We introduce stable ray tracing, a technique that improves temporal stability without the over-blurring and ghosting artifacts typical of temporal post-processing filters. Our technique is based on sample reprojection and explicit hole filling, rather than relying on hole-filling heuristics that can compromise image quality. We make reprojection practical in an interactive ray tracing context through the use of a super-resolution bitmask to estimate screen space sample density. We show significantly improved temporal stability as compared with supersampling and an existing reprojection techniques. We also investigate the performance and image quality differences between our technique and temporal antialiasing, which typically incurs a significant amount of blur. Finally, we demonstrate the benefits of stable ray tracing by combining it with progressive path tracing of indirect illumination.

We introduce a reconstruction algorithm that generates a temporally stable sequence of images from one path-per-pixel global illumination. To handle such noisy input, we use temporal accumulation to increase the e‚ective sample count and spatiotemporal luminance variance estimates to drive a hierarchical, image-space wavelet €lter [Dammertz et al. 2010]. Œis hierarchy allows us to distinguish between noise and detail at multiple scales using local luminance variance. Physically based light transport is a long-standing goal for realtime computer graphics. While modern games use limited forms of ray tracing, physically based Monte Carlo global illumination does not meet their 30 Hz minimal performance requirement. Looking Permission to make digital or hard copies of all or part of this work for personal or classroom use is granted without fee provided that copies are not made or distributed for pro€t or commercial advantage and that copies bear this notice and the full citation on the €rst page. Copyrights for components of this work owned by others than ACM must be honored. Abstracting with credit is permiŠed. To copy otherwise, or republish, to post on servers or to redistribute to lists, requires prior speci€c permission and/or a fee. Request permissions from permissions@acm.org. HPG ’17, Los Angeles, CA, USA © 2017 ACM. 978-1-4503-5101-0/17/07. . .$15.00 DOI: 10.1145/3105762.3105770 ahead to fully dynamic real-time path tracing, we expect this to only be feasible using a small number of paths per pixel. As such, image reconstruction using low sample counts is key to bringing path tracing to real-time. When compared to prior interactive reconstruction €lters, our work gives approximately 10× more temporally stable results, matches reference images 5–47% beŠer (according to SSIM), and runs in just 10 ms (± 15%) on modern graphics hardware at 1920×1080 resolution.

We introduce a reconstruction algorithm that generates a temporally stable sequence of images from one path-per-pixel global illumination. To handle such noisy input, we use temporal accumulation to increase the effective sample count and spatiotemporal luminance variance estimates to drive a hierarchical, image-space wavelet filter [Dammertz et al. 2010]. This hierarchy allows us to distinguish between noise and detail at multiple scales using local luminance variance. Physically based light transport is a long-standing goal for realtime computer graphics. While modern games use limited forms of ray tracing, physically based Monte Carlo global illumination does not meet their 30 Hz minimal performance requirement. Looking ahead to fully dynamic real-time path tracing, we expect this to only be feasible using a small number of paths per pixel. As such, image reconstruction using low sample counts is key to bringing path tracing to real-time. When compared to prior interactive reconstruction filters, our work gives approximately 10× more temporally stable results, matches reference images 5--47% better (according to SSIM), and runs in just 10 ms (± 15%) on modern graphics hardware at 1920×1080 resolution.

High-frequency illumination effects, such as highly glossy highlights on curved surfaces, are challenging to render in a stable manner. Such features can be much smaller than the area of a pixel and carry a high amount of energy due to high reflectance. These highlights are challenging to render in both offline rendering, where they require many samples and an outliers filter, and in real-time graphics, where they cause a significant amount of aliasing given the small budget of shading samples per pixel. In this paper, we propose a method for filtering the main source of highly glossy highlights in microfacet materials: the Normal Distribution Function (NDF). We provide a practical solution applicable for real-time rendering by employing recent advances in light transport for estimating the filtering region from various effects (such as pixel footprint) directly in the parallel-plane half-vector domain (also known as the slope domain), followed by filtering the NDF over this region. Our real-time method is GPU-friendly, temporally stable, and compatible with deferred shading, normal maps, as well as with filtering methods for normal maps.
