Programmable spatial shapers using liquid-crystal-based spatial-light-modulators in the National Ignition Facility lasers enable spatial shaping of the beam profile so that power delivered to the target can be maximized while maintaining system longevity. Programmable spatial shapers achieve three objectives: Introduce obscurations shadowing isolated flaws on downstream optical elements that could otherwise be affected by high fluence laser illumination; Spatial shaping to reduce beam peak-to-mean fluence variations to allow the laser to operate at higher powers so that maximum power can be delivered to the target; And finally gradually exposing the optical regions that have never seen laser light because they have always had shadowing from a blocker that is no longer needed. In this paper, we describe the control and image processing algorithms that determine beam shaping and verification of the beam profile. Calibration and transmittance mapping essential elements of controlling the PSS are described along with spatially nonlinear response of the device such as scale and rotation.

The heart of the National Ignition Facility is a megajoule-class laser system consisting of 192 beams used to drive inertial confinement fusion reactions. A recently installed system of programmable, liquid-crystal-based spatial light modulators adds the capability of arbitrarily shaping the spatial beam profiles in order to enhance operational flexibility. Its primary intended use is for introducing "blocker" obscurations shadowing isolated flaws on downstream optical elements that would otherwise be damaged by high fluence laser illumination. Because an improperly shaped blocker pattern can lead to equipment damage, both the position and shape of the obscurations must be carefully verified prior to high-fluence operations. An automatic alignment algorithm is used to perform detection and estimation of the imposed blocker centroid positions compared to their intended locations. Furthermore, in order to minimize the spatially-varying nonlinear response of the device, a calibration of the local magnification is performed at multiple sub-image locations. In this paper, we describe the control and associated image processing of this device that helps to enhance the safety and longevity of the overall system.
