Summary We describe techniques based on symbolic execution for finding software vulnerabilities that are due to algorithmic complexity. Such vulnerabilities allow an attacker to mount denial‐of‐service attacks to deny service to benign users or to otherwise disable a software system. The techniques use an efficient guided symbolic execution of a program to compute bounds on the worst‐case complexity (for increasing input sizes) and to generate test values that trigger the worst‐case behaviours. The resulting bounds are fitted to a function to obtain a prediction of the worst‐case program behaviour at any input size. Scalability is achieved by using path policies that guide the symbolic execution towards worst‐case paths. The policies are learned from the worst‐case results obtained with exhaustive exploration at small input sizes and are applied to guide exploration at larger input sizes, where unguided exhaustive exploration is not possible. To achieve precision in the analysis, the path policies take into account the history of choices made along the path when deciding which branch to execute next. Furthermore, the computation is contextpreserving, meaning that the decision for each branch depends on the history computed with respect to the enclosing method. We further report preliminary results on a complementary technique that uses machine learning for building the path policies that guide the search. The techniques are implemented in open‐source projects that build on the Symbolic Pathfinder tool for analysing Java programs. Experimental evaluation shows that the techniques can find vulnerabilities in complex Java programs and can outperform previous symbolic approaches.

The shift to cloud-based APIs has made application security critically depend on understanding and reasoning about policies that regulate access to cloud resources. We present stratified predicate abstraction , a new approach that summarizes complex security policies into a compact set of positive and declarative statements that precisely state who has access to a resource. We have implemented stratified abstraction and deployed it as the engine powering AWS’s IAM Access Analyzer service, and hence, demonstrate how formal methods and SMT can be used for security policy explanation .

Formal methods are mathematically based approaches for specifying, building, and reasoning about software. Despite 50 years of research and development, formal methods have had only limited impact in industry. While we have seen success in such domains as microprocessor design and aerospace (e.g., proofs of security properties for helicopter control systems1), we have not seen wide adoption of formal methods for large and complex systems, such as web services, industrial automation, or enterprise support software.

Symbolic execution is a systematic program analysis technique which executes programs on symbolic inputs, representing multiple concrete inputs, and represents the program behavior using mathematical constraints over the symbolic inputs. Solving the constraints with off-the-shelf solvers yields inputs that exercise different program paths. Typical applications of the technique include test input generation and error detection. In this chapter we review symbolic execution and associated tools, and describe some of the main challenges in applying symbolic execution in practice: handling of programs with complex inputs, coping with path explosion, and ameliorating the cost of constraint solving. We also survey promising applications of the technique that go beyond checking functional properties of programs. These include finding worst-case execution time in programs, load testing and security analysis, via combinations of symbolic execution with fuzzing.

Cloud computing provides on-demand access to IT resources via the Internet. Permissions for these resources are defined by expressive access control policies. This paper presents a formalization of the Amazon Web Services (AWS) policy language and a corresponding analysis tool, called ZELKOVA, for verifying policy properties. ZELKOVA encodes the semantics of policies into SMT, compares behaviors, and verifies properties. It provides users a sound mechanism to detect misconfigurations of their policies. ZELKOVA solves a PSPACE-complete problem and is invoked many millions of times daily.

We describe a heuristic analysis technique for finding costly paths in programs, where the cost refers to the execution time or memory consumed by the program. The analysis can support various software engineering tasks, such as finding vulnerabilities related to denial-of-service attacks, guiding compiler optimizations or finding performance bottlenecks in software. The analysis performs sampling over symbolic program paths, which are computed with a symbolic execution over the program, and uses Monte Carlo Tree Search (MCTS) to guide the search for costly paths. We implemented the proposed method in Symbolic PathFinder and we evaluated it on Java programs. Our experiments show the promise of the technique for finding performance bottlenecks in software.

In this paper we describe symbolic side-channel analysis techniques for detecting and quantifying information leakage, given in terms of Shannon and min-entropy. Measuring the precise leakage is challenging due to the randomness and noise often present in program executions and side-channel observations. We account for this noise by introducing additional (symbolic) program inputs which are interpreted probabilistically, using symbolic execution with parametrized model counting. We also explore a sampling approach for increased scalability. In contrast to typical Monte Carlo techniques, our approach works by sampling symbolic paths, representing multiple concrete paths, and uses pruning to accelerate computation and guarantee convergence to the optimal results. A key novelty of our approach is to provide bounds on the leakage that are provably under- and over-approximating the exact leakage. We implemented the techniques in the Symbolic PathFinder tool and demonstrate them on Java programs.

Testing is currently the main technique adopted by the industry for improving the quality, reliability, and security of software. In order to lower the cost of manual testing, automatic testing techniques have been devised, such as random and symbolic testing, with their respective trade-offs. For example, random testing excels at fast global exploration of software, while it plateaus when faced with hard-to-hit numerically-intensive execution paths. On the other hand, symbolic testing excels at exploring such paths, while it struggles when faced with complex heap class structures. In this paper, we describe an approach for automatic unit testing of object-oriented software that integrates the two techniques. We leverage feedback-directed unit testing to generate meaningful sequences of constructor+method invocations that create rich heap structures, and we in turn further explore these sequences using dynamic symbolic execution. We implement this approach in a tool called JDoop, which we augment with several parameters for fine-tuning its heuristics; such “knobs” allow for a detailed exploration of the various trade-offs that the proposed integration offers. Using JDoop, we perform an extensive empirical exploration of this space, and we describe lessons learned and guidelines for future research efforts in this area.

Summary We present HVM TP , a time predictable and portable Java virtual machine (JVM) implementation with applications in resource‐constrained, hard real‐time embedded systems, which implements all levels of the safety critical Java (SCJ) specification. Time predictability is achieved by a combination of time‐predictable algorithms, exploiting the programming model of the SCJ profile and harnessing static knowledge of the hosted SCJ system. This paper presents HVM TP in terms of its design and capabilities and demonstrates how a complete timing model of the JVM represented as a network of timed automata can be obtained using the tool T ETA SARTS JVM . The timing model readily integrates with the rest of the T ETA SARTS tool set for temporal verification of SCJ systems. We will also show how a complete timing scheme in terms of safe worst‐case execution times and best‐case execution times of the Java bytecodes can be derived from the model. Furthermore, we take a first look at how to support the new Java 8 language feature of Lambda expressions in a SCJ context – we look in particular at how the invokedynamic bytecode can be implemented in a time‐predictable way and integrated in HVM TP . Copyright © 2016 John Wiley & Sons, Ltd.

We present a rationale for a selection of tools that assist developers of hard real-time applications to verify that programs conform to a Java real-time profile and that platform-specific resource constraints are satisfied. These tools are specialized instances of more generic static analysis and model checking frameworks. The concepts are illustrated by a case study, and the strengths and the limitations of the tools are discussed.

We propose a technique based on symbolic execution for analyzing the algorithmic complexity of programs. The technique uses an efficient guided analysis to compute bounds on the worst-case complexity (for increasing input sizes) and to generate test values that trigger the worst-case behaviors. The resulting bounds are fitted to a function to obtain a prediction of the worst-case program behavior at any input sizes. Comparing these predictions to the programmers' expectations or to theoretical asymptotic bounds can reveal vulnerabilities or confirm that a program behaves as expected. To achieve scalability we use path policies to guide the symbolic execution towards worst-case paths. The policies are learned from the worst-case results obtained with exhaustive exploration at small input sizes and are applied to guide exploration at larger input sizes, where un-guided exhaustive exploration is no longer possible. To achieve precision we use path policies that take into account the history of choices made along the path when deciding which branch to execute next in the program. Furthermore, the history computation is context-preserving, meaning that the decision for each branch depends on the history computed with respect to the enclosing method. We implemented the technique in the Symbolic PathFinder tool. We show experimentally that it can find vulnerabilities in complex Java programs and can outperform established symbolic techniques.

In cyber-physical applications many programs have hard real-time constraints that have to be stringently validated. In some applications, there are programs that have hard deadlines, which must not be violated. Other programs have soft deadlines where the value of the response decreases when the deadline is passed although it is still a valid response. In between, there are programs with firm deadlines. Here the response may be occasionally delayed; but this should not happen too often or with too large an overshoot. This paper presents an extension to an existing approach and tool for checking hard deadline constraints to the case of firm deadlines for application programs written in Safety-Critical Java (SCJ). The existing approach uses models and model checking with the Uppaal toolset; the extension uses the statistical model checking features of Uppaal-smc to provide a hold on firm deadlines and performance in the case of soft deadlines. The extended approach is illustrated with examples from applications.

Grey-box fuzzing is a random testing technique that has been shown to be effective at finding security vulnerabilities in software. The technique leverages program instrumentation to gather information about the program with the goal of increasing the code coverage during fuzzing, which makes gray-box fuzzers extremely efficient vulnerability detection tools. One such tool is AFL, a grey-box fuzzer for C programs that has been used successfully to find security vulnerabilities and other critical defects in countless software products. We present Kelinci, a tool that interfaces AFL with instrumented Java programs. The tool does not require modifications to AFL and is easily parallelizable. Applying AFL-type fuzzing to Java programs opens up the possibility of testing Java based applications using this powerful technique. We show the effectiveness of Kelinci by applying it on the image processing library Apache Commons Imaging, in which it identified a bug within one hour.

The Java PathFinder extension Psyco generates interfaces of Java components using a combination of dynamic symbolic execution and automata learning to explore different combinations of method invocations on a component. Such interfaces are useful in contract-based compositional verification of component-based systems. Psyco relies on testing for validating learned interfaces and currently cannot guarantee that a generated interface is correct. Instead, it simply returns the most recent learned interface once a user-defined time limit is exceeded. In this paper, we report on work that was performed during the 2016 Google Summer of Code. The aim of this work is to extend Psyco with symbolic search. During symbolic search, Psyco uses fully symbolic method summaries for exploring the state space of a component symbolically. We plan to eventually use symbolic search to compute a termination criterion for Psyco that guarantees the correctness of learned interfaces (e.g., by using symbolic search as a basis for symbolically model-checking a component against a learned interface)

This paper explores the problem of managing movements of aircraft along the surface of busy airports. Airport surface management is a complex logistics problem involving the coordination of humans and machines. The work described here arose from the idea that autonomous towing vehicles for taxiing aircraft could offer a solution to the ’capacity problem’ for busy airports, the problem of getting more efficient use of existing surface area to meet increasing demand. Supporting autonomous surface operations requires continuous planning, scheduling and monitoring of operations, as well as systems for optimizing complex human-machine interaction. We identify a set of computational subproblems of the surface management problem that would benefit from recent advances in multi-agent planning and scheduling and probabilistic predictive modeling, and discuss preliminary work at integrating these components into a prototype of a surface management system.

We present LOG2MODEL, an approach, supported by a tool, that builds behavioral models from log data. The logged data consists of time series encoding the values of the states of a system observed at discrete time steps. The models generated are Discrete-Time Markov Chains with states and transitions representing the values recorded in the log. The models contain key information that can be visualized and analyzed with respect to safety, delays, throughput etc, using off-the-shelf model checkers such as PRISM. The analysis results can be further used by users or automated tools to monitor and alter the system behavior. We present the architecture of LOG2MODEL and its application in the context of autonomous operations in the airspace domain.

We describe JDart, a dynamic symbolic analysis framework for Java. A distinguishing feature of JDart is its modular architecture: the main component that performs dynamic exploration communicates with a component that efficiently constructs constraints and that interfaces with constraint solvers. These components can easily be extended or modified to support multiple constraint solvers or different exploration strategies. Moreover, JDart has been engineered for robustness, driven by the need to handle complex NASA software. These characteristics, together with its recent open sourcing, make JDart an ideal platform for research and experimentation. In the current release, JDart supports the CORAL, SMTInterpol, and Z3 solvers, and is able to handle NASA software with constraints containing bit operations, floating point arithmetic, and complex arithmetic operations e.g., trigonometric and nonlinear. We illustrate how JDart has been used to support other analysis techniques, such as automated interface generation and testing of libraries. Finally, we demonstrate the versatility and effectiveness of JDart, and compare it with state-of-the-art dynamic or pure symbolic execution engines through an extensive experimental evaluation.

Symbolic Execution is a program analysis technique used to increase software reliability. Modern software often manipulate complex data structures, many of which being similar to arrays. We present a novel approach and implementation in Symbolic PathFinder for handling symbolic arrays in Java. It enables analyzing a broader class of programs that manipulates arrays. We also extend the Symbolic Pathfinder testcase generation to support numeric arrays.

This paper presents SymRT, a tool based on a combination of symbolic execution and real-time model checking for timing analysis of Java systems. Symbolic execution is used for the generation of a safe and tight timing model of the analyzed system capturing the feasible execution paths. The model is combined with suitable execution environment models capturing the timing behavior of the target host platform including the Java virtual machine and complex hardware features such as caching. The complete timing model is a network of timed automata which directly facilitates safe estimates of worst and best case execution time to be determined using the Uppaal model checker. Furthermore, the integration of the proposed techniques into the TetaSARTS tool facilitates reasoning about additional timing properties such as the schedulability of periodically and sporadically released Java real-time tasks (under specific scheduling policies), worst case response time, and more.

The idea of analysing real programs by process algebraic methods probably goes back to the Occam language using the CSP process algebra [43]. In [16,24] Degano et al. followed in that tradition by analysing Mobile Agent Programs written in the Higher Order Functional, Concurrent and Distributed, programming language Facile [47], by equipping Facile with a process algebraic semantics based on true concurrency. This semantics facilitated analysis of programs revealing subtle bugs that would otherwise be very hard to find. Inspired by the idea of translating real programs into process algebraic frameworks, we have in recent years pursued an agenda of translating hard-real-time embedded safety critical programs written in the Safety Critical Java Profile [33] into networks of timed automata [4] and subjecting those to automated analysis using the UPPAAL model checker [10]. Several tools have been built and the tools have been used to analyse a number of systems for properties such as worst case execution time, schedulability and energy optimization [12-14,19,34,36,38]. In this paper we will elaborate on the theoretical underpinning of the translation from Java programs to timed automata models and briefly summarize some of the results based on this translation. Furthermore, we discuss future work, especially relations to the work in [16,24] as Java recently has adopted first class higher order functions in the form of lambda abstractions.
