The Statewide Southern California Earthquake Center (SCEC) has designed and implemented CyberShake (CS), a high-performance computing (HPC) workflow to undertake Physics-Based Probabilistic Seismic Hazard Analysis (PB-PSHA) in California (CA). Here, we have ported CS from CA to the South Iceland Seismic Zone (SISZ) and the Reykjanes Peninsula Oblique Rift (RPOR), which experience sinistral transform motion and pose a very high earthquake risk to about 2/3 of the Iceland population. We consider a realization of the 3D SISZ-RPOR fault system, where fault areas are estimated from event magnitude through a scaling law (Mai & Beroza, 2017), that fits maximum fault extents observed from slip inversions and surface mappings. The magnitude variability across the modeling region (~63.8°- 64.1°N, ~20°-23°W) is Mw 5-7. In this work, we employ CS to model ~2100 kinematic earthquake ruptures and quantify the resulting ground motion (GM) in terms of Pseudo Spectral Acceleration (PSA) intensity measures. An important computational milestone is the software development of an open-source in-house workflow manager at the Marenostrum Supercomputer that replaces the one used in CA by SCEC based on Pegasus and HTCondor. This new workflow manager handles input data (fault-plane geometries, rupture magnitudes, surface stations for GM recording and hazard studies), orchestrates the execution of CS components, and stores results (particle velocity seismograms and hazard curves). Among these components, the Graves-Pitarka (GP) kinematic rupture generator is used to produce finite-fault source descriptions characterized by a few large asperities. The other important component is the open-source fourth-order finite-difference staggered-grid AWP-ODC earthquake simulation code that allows for reciprocity and efficiently simulates rupture and seismic wave propagation in 3D heterogeneous Earth models. CS uses an adjoint computational procedure in which simulations of wave propagation are performed using a polarized delta source to compute the Strain Green Tensors (SGTs) at each fault point. The convolution of SGTs with GP ruptures yields particle-velocity seismograms at each station. SGT time histories are memory demanding, but the adjoint calculations are completely independent and therefore embarrassing parallel, making CS a highly efficient earthquake simulation tool. In this study, SGTs are constructed using a source frequency range of 0-1.0 Hz, generating ground motion synthetics resolved up to 0.5 Hz. CS rotation-invariant PSA values (3 and 5 sec periods) computed from our study show a good agreement with updated Bayesian ground motion prediction equations (Kowsari et al, 2022). This study is a first step towards a PB-PSHA in the SISZ-RPOR region and to routinely apply Cybershake outside of California.REFERENCES:Mai, M., & Beroza, G. Source scaling properties from finite-fault-rupture models. Bulletin of the Seismological Society of America, 90(3), 604-615, 2000.Kowsari, M., Sonnemann, T., Halldorsson, B., Hrafnkelsson, B., Snæbjörnsson, J. & Jonsson, S. Bayesian inference of empirical ground motion models to pseudo-spectral accelerations of South Iceland Seismic Zone earthquakes based on informative priors. Soil Dynamics and Earthquake Engineering, 132, 106075, 2020.

The ShakeOut scenario of a M7.8 northwestward rupture on the southern San Andreas fault (SSAF) (Jones et al., 2008) predicted significant long-period ground motion amplification in the greater Los Angeles, CA, area, caused by a waveguide from interconnected sedimentary basins. However, the early ShakeOut ground motion simulations omitted important model features with immature versions of the velocity structure and fault geometry. Here, we present 0-1 Hz 3D numerical wave propagation simulations for the ShakeOut scenario including surface topography, as well as updated high-resolution velocity structure and SSAF fault geometry. Spectral Accelerations at 3s are increased by the local high-resolution basin models (25-45%) but decreased from complexity in velocity and density updates outside the basins (65-100%) and inclusion of surface topography (~30%). The updated model reduces peak ground velocities in the waveguide from ~250 cm/s to ~100 cm/s, significantly closer to the values predicted by a leading NGA-West2 ground motion model.

Earthquakes on the Salt Lake City Segment of the Wasatch fault (WFSLC) represent the most significant seismic hazard to the Salt Lake Valley, populated by 1 million+ people. The 2020 Magna, UT, earthquake, which likely occurred on the WFSLC, generated peak ground accelerations (PGAs) as large as 0.55 g in the Salt Lake Valley. Here, we present three-dimensional (3D) physics-based wave propagation simulations of the Magna earthquake sequence in the Wasatch Front Community Velocity Model (WFCVM) up to 10 Hz to better constrain both linear and nonlinear parameters in the soils of the Salt Lake Valley. We first calibrate the WFCVM via linear simulations of a [Formula: see text]4.59 Magna aftershock, obtaining the best fit between the recordings and synthetics, including a statistical distribution of small-scale heterogeneities with 10% standard deviation and [Formula: see text] for frequencies [Formula: see text] Hz and [Formula: see text] for frequencies [Formula: see text] Hz ([Formula: see text] in m/s). Spectral ratios from our simulations of the 2020 Magna mainshock using a finite-fault source model generally overestimate those for the recordings in the linear regime at higher frequencies, in particular at stations with the largest PGAs, suggesting the presence of nonlinear soil effects. Using a fully hysteretic multi-yield-surface 3D nonlinear modeling approach, we find that damping from the reference strain–depth relations proposed by Darendeli significantly reduces the bias in terms of spectral amplification ratios at stations with the shortest epicentral distances. We find an optimal fit between the recordings and nonlinear synthetics for reference strains at about 2 standard deviations below Darendeli’s relations, with reduction of the spectral amplification bias by more than a factor of two. Our findings suggest significant nonlinear soil effects in the Salt Lake Valley and provide a basis for improved seismic hazard analysis of the greater Salt Lake City region.

CyberShake is a high-performance computing workflow for kinematic fault-rupture and earthquake ground-motion simulation developed by the Statewide California Earthquake Center to facilitate physics-based probabilistic seismic hazard assessment (PSHA). CyberShake exploits seismic reciprocity for wave propagation by computing strain green tensors along fault planes, which in turn are convolved with rupture models to generate surface seismograms. Combined with a faultwide hypocentral variation of each simulated rupture, this procedure allows for generating ground-motion synthetics that account for realistic source variability. This study validates the platform's kinematic modeling of physics-based seismic wave propagation simulations in Southwest Iceland as the first step toward migrating CyberShake from its original study region in California. Specifically, we have implemented CyberShake workflows to model 2103 fault ruptures and simulate the corresponding two horizontal components of ground-motion velocity on a 5 km grid of 625 stations in Southwest Iceland. A 500-yr-long earthquake rupture forecast consisting of 223 hypothetical finite-fault sources of M-w 5-7 was generated using a physics-based model of the bookshelf fault system of the Southwest Iceland transform zone. For each station, every reciprocal simulation uses 0-1 Hz Gaussian point sources polarized along two horizontal grid directions. Comparison of the results in the form of rotation-invariant synthetic pseudoacceleration spectral response values at 3, 4, and 5 s periods are in good agreement with the Icelandic strong motion data set and a suite of empirical Bayesian ground-motion prediction equations (GMPEs). The vast majority of the physics-based simulations fall within one standard deviation of the mean GMPE predictions, previously estimated for the area. At large magnitudes for which no data exist in Iceland, the synthetic data set may play an important role in constraining GMPEs for future applications. Our results comprise the first step toward comprehensive and physics-based PSHA for Southwest Iceland.

We propose an approach to fuse multiresolution seismic tomography models with physics-informed probability graphical models (PIPGMs), which consider the physical information (ray-path density). To evaluate the efficacy of the PIPGM fusion method, we use both synthetic checkerboard models and real fault zone structures imaged from 2019 Ridgecrest, CA, earthquake sequence. The proposed method improves the combined models in terms of travel time residual, image quality, and peak signal-to-noise ratio, compared to those obtained by multiple conventional methods. The proposed fusion method can merge any type of gridded multi-resolution velocity model, a valuable tool for computational imaging.

We have conducted three-dimensional (3D) 0–7.5 Hz physics-based wave propagation simulations to model the seismic response of the Long Valley Dam (LVD), which has formed Lake Crowley in Central California, to estimate peak ground motions and settlement of the dam expected during maximum credible earthquake (MCE) scenarios on the nearby Hilton Creek Fault (HCF). We calibrated the velocity structure, anelastic attenuation model, and the overall elastic properties of the dam via linear simulations of a M w 3.7 event as well as the M w 6.2 Chalfant Valley earthquake of 1986, constrained by observed ground motions on and nearby the LVD. The Statewide California Earthquake Center (SCEC) Community Velocity Model CVM-S4.26.M01 superimposed with a geotechnical layer using [Formula: see text] information tapered from the surface to a 700-m depth was used in the simulations. We found optimal fit of simulated and observed ground motions at the LVD using frequency-independent attenuation of [Formula: see text] ([Formula: see text] in m/s). Using the calibrated model, we simulated 3D nonlinear ground motions at the LVD for M w 6.6 rupture scenarios on the HCF using an Iwan-type, multi-yield-surface technique. We use a two-step method where the computationally expensive nonlinear calculations were carried out in a small domain with the plane wave excitation along the bottom boundary obtained from a full-domain 3D linear finite-fault simulation. Our nonlinear MCE simulation results show that peak ground velocities (PGVs) and peak ground accelerations (PGAs) as high as 72 cm/s and 0.55 g, respectively, can be expected at the crest of the LVD. Compared with linear ground motion simulation results, our results show that Iwan nonlinear damping reduces PGAs on the dam crest by up to a factor of 8 and increasingly depletes the high-frequency content of the waves toward the dam crest. We find horizontal relative displacements of the material inside the dam of up to [Formula: see text] and up to [Formula: see text] of vertical subsidence, equivalent to 1% of the dam height.

CyberShake (CS) is a high-performance computing workflow for Probabilistic Seismic Hazard Assessment (PSHA) developed by the Statewide California Earthquake Center. Here, we employ CS to generate a set of 2103 fault ruptures and simulate the corresponding two horizontal velocity components time histories of ground motion (GM) on a 5-km grid of 625 stations in Southwest Iceland (SI). The ruptures were defined on a new synthetic time-independent 500-year catalog consisting of 223 hypothetical finite-fault sources of 5-7, generated using a new physics-based bookshelf fault system model in the SI transform zone. This fault system model and rupture realizations enable the CS time-independent physics-based approach to PSHA in the region. The study aims to migrate CS to SI and validate its kinematic fault rupture, anelastic wave propagation and ground motion simulations. Toward this goal, we use CS to generate multiple finite-fault rupture variations for each hypothetical fault. CS exploits seismic reciprocity for wave propagation by computing Strain Green Tensors along fault planes, which in turn are convolved with rupture models to generate GM seismograms. For each GM recording station, every adjoint simulation uses a 0-1 Hz Gaussian point source polarized along one horizontal grid direction. Comparison of the results in the form of rotation-invariant synthetic pseudo-acceleration spectral response values at 2, 3 and 5 sec periods are in very good agreement with the Icelandic strong-motion dataset, and a suite of new empirical Bayesian ground motion prediction equations (GMPEs). The vast majority of the CS results fall within one standard deviation of the mean GMPE predictions, previously estimated for the area. Importantly, at large magnitudes for which no data exists in Iceland, the CS dataset may play an important role in constraining the GMPEs for future applications.

AWP-ODC is an open-source dynamic rupture and wave propagation code which solves the 3D velocity-stress wave equation explicitly by a staggered-grid finite-difference method with fourth-order accuracy in space and second-order accuracy in time. The code is memory-bandwidth, with excellent scalability up to full machine scale on CPUs and GPUs, tuned on CLX, with support for generating vector folded finite difference stencils using intrinsic functions. AWP-ODC includes frequency-dependent anelastic attenuation Q(f), small-scale media heterogeneities, support for topography, Drucker-Prager visco-plasticity, and a multi-yield-surface, hysteretic (Iwan) nonlinear model using an overlay concept. Support for a discontinuous mesh is available for increased efficiency. An important application of AWP-ODC is the CyberShake Strain-Green-Tensor (SGT) code used for probabilistic hazard analysis in CA and other regions. Here, we summarize implementation and verification of some of the widely-used capabilities of AWP-ODC, as well as validation against strong motion data and recent applications for future earthquake scenarios. We show for a M7.8 dynamic rupture ShakeOut scenario on the southern San Andreas fault that while simulations with a single yield surface reduces long period ground motion amplitudes by about 25% inside a wave guide in greater Los Angeles, multi-surface Iwan nonlinearity further reduces the values by a factor of two. In addition, we show assembly and calibration of a 3D Community Velocity Model (CVM) for central and southern Chile as well as Peru. The CVM is validated for the 2010 M8.8 Maule, Chile, earthquake up to 5 Hz, and the validated CVM is used for scenario simulations of megathrust scenario events with magnitude up to M9.5 in the Chile-Peru subduction zone for risk assessment. Finally, we show simulations of 0-3 Hz 3D wave propagation for the 2019 Mw 7.1 Ridgecrest earthquake including a data-constrained high-resolution fault-zone model. Our results show that the heterogeneous near-fault low-velocity zone inherent to the fault zone structure significantly perturbs the predicted wave field in the near-source region, in particular by more accurately generating Love waves at its boundaries, in better agreement with observations, including at distances 200+ km in Los Angeles.

Scientific workflows are key to supporting the execution of large-scale simulations in many scientific domains, including solid earth geophysics. Although many different workflow tools exist, they share common features, enabling application developers to express their simulations as a series of linked software elements with data dependencies and then execute the workflow efficiently on distributed resources. To illustrate the use and benefits of scientific workflows in seismic applications, this talk will describe CyberShake, a probabilistic seismic hazard analysis (PSHA) platform developed by the Southern California Earthquake Center (SCEC). CyberShake uses 3D physics-based wave propagation simulations with reciprocity to calculate ground motions for events from an earthquake rupture forecast (ERF). Typically, CyberShake considers over 500,000 events per site of interest, and then combines the individual ground motions with probabilities from the ERF to produce site-specific PSHA curves. CyberShake has integrated modules from another SCEC workflow application, the Broadband Platform (BBP), enabling CyberShake simulations to include both low-frequency deterministic and high-frequency stochastic content. This talk will discuss the workflow framework that CyberShake utilizes to support campaigns requiring hundreds of thousands of node-hours over months of wall clock time, and the lessons learned through 15 years of CyberShake simulations. This talk will also reflect on the growth and development of workflow-based simulations and explore the challenges faced by applications in the exascale era, such as managing massive volumes of data, taking full advantage of exascale systems, and the emergence of AI-informed simulations. The talk will discuss ways in which workflow technologies may help mitigate these challenges as we move our science forward.

SUMMARY The resolution of velocity models obtained by tomography varies due to multiple factors and variables, such as the inversion approach, ray coverage, data quality, etc. Combining velocity models with different resolutions can enable more accurate ground motion simulations. Toward this goal, we present a novel methodology to fuse multiresolution seismic velocity maps with probabilistic graphical models (PGMs). The PGMs provide segmentation results, corresponding to various velocity intervals, in seismic velocity models with different resolutions. Further, by considering physical information (such as ray path density), we introduce physics-informed probabilistic graphical models (PIPGMs). These models provide data-driven relations between subdomains with low (LR) and high (HR) resolutions. Transferring (segmented) distribution information from the HR regions enhances the details in the LR regions by solving a maximum likelihood problem with prior knowledge from HR models. When updating areas bordering HR and LR regions, a patch-scanning policy is adopted to consider local patterns and avoid sharp boundaries. To evaluate the efficacy of the proposed PGM fusion method, we tested the fusion approach on both a synthetic checkerboard model and a fault zone structure imaged from the 2019 Ridgecrest, CA, earthquake sequence. The Ridgecrest fault zone image consists of a shallow (top 1 km) high-resolution shear-wave velocity model obtained from ambient noise tomography, which is embedded into the coarser Statewide California Earthquake Center Community Velocity Model version S4.26-M01. The model efficacy is underscored by the deviation between observed and calculated traveltimes along the boundaries between HR and LR regions, 38 per cent less than obtained by conventional Gaussian interpolation. The proposed PGM fusion method can merge any gridded multiresolution velocity model, a valuable tool for computational seismology and ground motion estimation.

The Statewide (formerly Southern) California Earthquake Center (SCEC) conducts multidisciplinary earthquake system science research that aims to develop predictive models of earthquake processes, and to produce accurate seismic hazard information that can improve societal preparedness and resiliency to earthquake hazards. As part of this program, SCEC has developed the CyberShake platform, which calculates physics-based probabilistic seismic hazard analysis (PSHA) models for regions with high-quality seismic velocity and fault models. The CyberShake platform implements a sophisticated computational workflow that includes over 15 individual codes written by 6 developers. These codes are heterogeneous, ranging from short-running high-throughput serial CPU codes to large, long-running, parallel GPU codes. Additionally, CyberShake simulation campaigns are computationally extensive, typically producing tens of terabytes of meaningful scientific data and metadata over several months of around-the-clock execution on leadership-class supercomputers. To meet the needs of the CyberShake platform, we have developed an extreme-scale workflow stack, including the Pegasus Workflow Management System, HTCondor, Globus, and custom tools. We present this workflow software stack and identify how the CyberShake platform and supporting tools enable us to meet a variety of challenges that come with large-scale simulations, such as automated remote job submission, data management, and verification and validation. This platform enabled us to perform our most recent simulation campaign, CyberShake Study 22.12, from December 2022 to April 2023. During this time, our workflow tools executed approximately 32,000 jobs, and used up to 73% of the Summit system at Oak Ridge Leadership Computing Facility. Our workflow tools managed about 2.5 PB of total temporary and output data, and automatically staged 19 million output files totaling 74 TB back to archival storage on the University of Southern California's Center for Advanced Research Computing systems, including file-based relational data and large binary files to efficiently store millions of simulated seismograms. CyberShake extreme-scale workflows have generated simulation-based probabilistic seismic hazard models that are being used by seismological, engineering, and governmental communities.

ABSTRACT We have implemented and verified a parallel-series Iwan-type nonlinear model in a 3D fourth-order staggered-grid velocity–stress finite-difference method. The Masing unloading and reloading behavior is simulated by tracking an overlay of concentric von Mises yield surfaces. Lamé parameters and failure stresses pertaining to each surface are calibrated to reproduce the stress–strain backbone curve, which is controlled by the reference strain assigned to a given depth level. The implementation is successfully verified against established codes for 1D and 2D SH-wave benchmarks. The capabilities of the method for large-scale nonlinear earthquake modeling are demonstrated for an Mw 7.8 dynamic rupture ShakeOut scenario on the southern San Andreas fault. Although ShakeOut simulations with a single yield surface reduces long-period ground-motion amplitudes by about 25% inside a waveguide in greater Los Angeles, Iwan nonlinearity further reduces the values by a factor of 2. For example, inside the Whittier Narrows corridor spectral accelerations at a period of 3 s are reduced from 1g in the linear case to about 0.8 in the bilinear case and to 0.3–0.4g in the multisurface Iwan nonlinear case, depending on the choice of reference strain. Normalized shear modulus reductions reach values of up to 50% in the waveguide and up to 75% in the San Bernardino basin at the San Andreas fault. We expect the implementation to be a valuable tool for future nonlinear 3D dynamic rupture and ground-motion simulations in models with coupled source, path, and site effects.

ABSTRACT We have simulated 0–3 Hz deterministic wave propagation in the Southern California Earthquake Center Community Velocity Model (CVM) version CVM-S4.26-M01 for the 2019 Mw 7.1 Ridgecrest earthquake. A data-constrained high-resolution fault zone model (Zhou et al., 2022) is incorporated into the CVM to investigate the effects of the near-fault low-velocity zone (LVZ) on the resulting ground motions, constrained by strong-motion data recorded at 161 stations. The finite-fault source used for the simulation of the Ridgecrest event was obtained from the Liu et al. (2019) kinematic inversion, enriched by noise following a von Karman correlation function above ∼1 Hz with a f−2 high-frequency decay. Our results show that the heterogeneous near-fault LVZ inherent to the fault zone structure significantly perturbs the predicted wave field in the near-source region, in particular by more accurately generating Love waves at its boundaries. The fault zone decreases the 0.1–0.5 Hz mean absolute Fourier amplitude spectrum bias to seismic recordings for all sites in the model and in the Los Angeles basin area (∼200 km from the source) by 16% and 26%, respectively. The fault zone structure generally improves modeling of the long-period features in the data and lengthens the coda-wave trains, in better agreement with observations. The favorable fit to data was obtained with a model including high-resolution surface topography, a 700-m-thick geotechnical layer and frequency-dependent anelastic attenuation in the model domain, with QS=0.1VS and QS(f)=0.1VSf0.5 (VS in m/s) for frequencies lower and higher than 1 Hz, respectively. We recommend that a data-constrained fault zone velocity structure, where available, be included in ground-motion modeling to obtain the least-biased fit to observed seismic data.

First posted December 15, 2022 For additional information, contact: Associate Director, Ecosystems Mission AreaU.S. Geological Survey12201 Sunrise Valley Drive, MS 300Reston, VA 20192 Ungulates (hooved mammals) have a broad distribution across the western United States and play an important role in maintaining predator-prey dynamics, affecting vegetation communities, and providing economic benefits to regional communities through tourism and hunting. Throughout the diverse landscapes they occupy, many ungulate populations undertake seasonal migrations to exploit spatially and temporally variable resources and to avoid predation or other threats. As the human footprint continues to expand across the western United States, ungulates increasingly face more obstacles on their migratory journeys. These obstacles threaten the long-term persistence of existing migrations. As a result, wildlife management agencies across the western United States have worked to identify and protect (or enhance) ungulate migration corridors and seasonal ranges identified from global positioning system (GPS) collar data. These efforts garnered additional support through the U.S. Department of the Interior Secretarial Order (SO) 3362, which was initiated in 2018 and provided Federal support for enhancing habitat quality of big-game winter ranges and migration corridors across the western states.Further, SO 3362 prompted the U.S. Geological Survey (USGS) to establish the Corridor Mapping Team (CMT): a collaboration between USGS and participating State and Federal wildlife management agencies, as well as numerous Tribal Nations. The CMT works collaboratively to map ungulate migrations and seasonal ranges throughout the western United States within the Ungulate Migrations of the Western United States report series. Volume 1 of the series was published in 2020 and contained migrations and winter ranges from 42 herds across 5 states. Volume 2 was published in 2022 and contained migrations and seasonal ranges from an additional 65 herds. This report, Volume 3 in the series, details migrations and seasonal ranges from an additional 45 herds throughout most western states. In aggregate, the report series has detailed and mapped the migrations and seasonal ranges of 152 ungulate herds and serves as a map-based inventory of the documented ungulate migrations across the western United States. The data layers for most of the herds included in the report series are also available to the public by the USGS. In addition to the included herd maps, this volume provides an overview of the many ways the mapping efforts associated with the CMT are being integrated into local conservation, management, and policy throughout the western United States.

We perform ambient noise tomography using data recorded on 342 seismographs within a 50 × 50 km area inside which the July 2019 M7.1 and M6.4 Ridgecrest earthquakes occurred. We used the locally sparse tomography (LST) method, an unsupervised machine learning approach that learns to represent small‐scale geophysical structures using only data from the immediate study. The Rayleigh group speed obtained from LST better predicts travel times than conventional regularized least squares inversion. The 3D shear velocity model of the area obtained from the surface wave dispersion maps reveals a highly heterogeneous low‐velocity zone (with the primary velocity reduction in the upper 2–3 km) around the causative faults for the M7.1 and M6.4 events, with a 40% reduction of the shear wave velocity. Further, correlation of other imaged LVZs in the model area with parts of the Little Lake Fault System without recent activity may indicate long‐lasting damage zones.

SUMMARYWe have simulated 0–5 Hz deterministic wave propagation for a suite of 17 models of the 2014 Mw 5.1 La Habra, CA, earthquake with the Southern California Earthquake Center Community Velocity Model Version S4.26-M01 using a finite-fault source. Strong motion data at 259 sites within a 148 km × 140 km area are used to validate our simulations. Our simulations quantify the effects of statistical distributions of small-scale crustal heterogeneities (SSHs), frequency-dependent attenuation Q(f), surface topography and near-surface low-velocity material (via a 1-D approximation) on the resulting ground motion synthetics. The shear wave quality factor QS(f) is parametrized as QS, 0 and QS, 0fγ for frequencies less than and higher than 1 Hz, respectively. We find the most favourable fit to data for models using ratios of QS, 0 to shear wave velocity VS of 0.075–1.0 and γ values less than 0.6, with the best-fitting amplitude drop-off for the higher frequencies obtained for γ values of 0.2–0.4. Models including topography and a realistic near-surface weathering layer tend to increase peak velocities at mountain peaks and ridges, with a corresponding decrease behind the peaks and ridges in the direction of wave propagation. We find a clear negative correlation between the effects on peak ground velocity amplification and duration lengthening, suggesting that topography redistributes seismic energy from the large-amplitude first arrivals to the adjacent coda waves. A weathering layer with realistic near-surface low velocities is found to enhance the amplification at mountain peaks and ridges, and may partly explain the underprediction of the effects of topography on ground motions found in models. Our models including topography tend to improve the fit to data, as compared to models with a flat free surface, while our distributions of SSHs with constraints from borehole data fail to significantly improve the fit. Accuracy of the velocity model, particularly the near-surface low velocities, as well as the source description, controls the resolution with which the anelastic attenuation can be determined. Our results demonstrate that it is feasible to use fully deterministic physics-based simulations to estimate ground motions for seismic hazard analysis up to 5 Hz. Here, the effects of, and trade-offs with, near-surface low-velocity material, topography, SSHs and Q(f) become increasingly important as frequencies increase towards 5 Hz, and should be included in the calculations. Future improvement in community velocity models, wider access to computational resources, more efficient numerical codes and guidance from this study are bound to further constrain the ground motion models, leading to more accurate seismic hazard analysis.

SUMMARYThe near-surface seismic structure (to a depth of about 1000 m), particularly the shear wave velocity (VS), can strongly affect the propagation of seismic waves and, therefore, must be accurately calibrated for ground motion simulations and seismic hazard assessment. The VS of the top (<300 m) crust is often well characterized from borehole studies, geotechnical measurements, and water and oil wells, while the velocities of the material deeper than about 1000 m are typically determined by tomography studies. However, in depth ranges lacking information on shallow lithological stratification, typically rock sites outside the sedimentary basins, the material parameters between these two regions are typically poorly characterized due to resolution limits of seismic tomography. When the alluded geological constraints are not available, models, such as the Southern California Earthquake Center (SCEC) Community Velocity Models (CVMs), default to regional tomographic estimates that do not resolve the uppermost VS values, and therefore deliver unrealistically high shallow VS estimates. The SCEC Unified Community Velocity Model (UCVM) software includes a method to incorporate the near-surface earth structure by applying a generic overlay based on measurements of time-averaged VS in top 30 m (VS30) to taper the upper part of the model to merge with tomography at a depth of 350 m, which can be applied to any of the velocity models accessible through UCVM. However, our 3-D simulations of the 2014 Mw 5.1 La Habra earthquake in the Los Angeles area using the CVM-S4.26.M01 model significantly underpredict low-frequency (<1 Hz) ground motions at sites where the material properties in the top 350 m are significantly modified by the generic overlay (‘taper’). On the other hand, extending the VS30-based taper of the shallow velocities down to a depth of about 1000 m improves the fit between our synthetics and seismic data at those sites, without compromising the fit at well-constrained sites. We explore various tapering depths, demonstrating increasing amplification as the tapering depth increases, and the model with 1000 m tapering depth yields overall favourable results. Effects of varying anelastic attenuation are small compared to effects of velocity tapering and do not significantly bias the estimated tapering depth. Although a uniform tapering depth is adopted in the models, we observe some spatial variabilities that may further improve our method.

Traditional Probabilistic Seismic Hazard Analysis (PSHA) estimates the level of earthquake ground shaking that is expected to be exceeded with a given recurrence time on the basis of historical earthquake catalogues and empirical and time-independent Ground Motion Prediction Equations (GMPEs). The smooth nature of GMPEs usually disregards some well known drivers of ground motion characteristics associated with fault rupture processes, in particular in the near-fault region, complex source-site propagation of seismic waves, and sedimentary basin response. Modern physics-based earthquake simulations can consider all these effects, but require a large set of input parameters for which constraints may often be scarce. However, with the aid of high-performance computing (HPC) infrastructures the parameter space may be sampled in an efficient and scalable manner allowing for a large suite of site-specific ground motion simulations that approach the center, body and range of expected ground motions. CyberShake is a HPC platform designed to undertake physics-based PSHA from a large suite of earthquake simulations. These simulations are based on seismic reciprocity, rendering PSHA computationally tractable for hundreds of thousands potential earthquakes. For each site of interest, multiple kinematic rupture scenarios, derived by varying slip distributions and hypocenter location across the pre-defined fault system, are generated from an input Earthquake Forecast Model (EFM). Each event is simulated to determine ground motion intensities, which are synthesized into hazard results. CyberShake has been developed by the Southern California Earthquake Center, and used so far to assess seismic hazard in California. This work focuses on the CyberShake migration to the seismic region of South Iceland (63.5°- 64.5°N, 20°-22°W) where the largely sinistral East-West transform motion across the tectonic margin is taken up by a complex array of near-vertical and parallel North-South oriented dextral transform faults in the South Iceland Seismic Zone (SISZ) and the Reykjanes Peninsula Oblique Rift (RPOR). Here, we describe the main steps of migrating CyberShake to the SISZ and RPOR, starting by setting up a relational input database describing potential causative faults and rupture characteristics, and key sites of interest. To simulate our EFM, we use the open source code SHERIFS, a logic-tree method that converts the slip rates of complex fault systems to the corresponding annual seismicity rate. The fault slip rates are taken from a new 3D physics-based fault model for the SISZ-RPOR transform fault system. To validate model and simulation parameters, two validation steps using key CyberShake modeling tools have been carried out. First, we perform simulations of historical earthquakes and compare the synthetics with recorded ground motions and results from other forward simulations. Second, we adjust the rupture kinematics to make slip distributions more representative of SISZ-type earthquakes by comparing with static slip distributions of past significant earthquakes. Finally, we run CyberShake and compare key parameters of the synthetic ground motions with new GMPEs available for the study region. The successful migration and use of CyberShake in South Iceland is the first step of a full-scale physics-based PSHA in the region, and showcases the implementation of CyberShake in new regions.

Ground motion time series recorded at stations separated by up to about 50 km show a frequency-dependent spatial coherency structure, and the corresponding ground motion intensity measures are found to be correlated. As omitting this correlation can result in underestimation of seismic losses in risk analysis, it is critical to quantify the spatial correlation structure for ground motion Fourier spectra estimated at different sites during a single event within a region. Toward this goal, we have developed an empirical frequency-dependent spatial correlation model for the within-event residuals of effective Fourier amplitude spectra from the Pacific Earthquake Engineering Research Center (PEER) Next Generation Attenuation (NGA) West2 database. The correlation model shows slower decrease of the spatial correlation with distance at lower frequencies compared with higher frequencies, in agreement with the underlying ground motion data, and no significant dependence on the magnitude of the earthquakes is observed. We use this empirical model to incorporate frequency-dependent spatial correlation into a hybrid deterministic-stochastic broadband ground motion generation module, which successfully generates synthetic time series for seven western US earthquakes with frequency-dependent spatial correlation that closely mimics that of the empirical model. Furthermore, the method also significantly improves the correlation for spectral accelerations, cumulative absolute velocities, and Arias intensities, compared with that derived from the original broadband module.
