Evidence that in vivo bacteriophage T3 DNA packaging includes capsid hyper-expansion that is triggered by lengthening of incompletely packaged DNA (ipDNA) is presented here. This evidence includes observation that some of the longer ipDNAs in T3-infected cells are packaged in ipDNA-containing capsids with hyper-expanded outer shells (HE ipDNA-capsids). In addition, artificially induced hyper-expansion is observed for the outer shell of a DNA-free capsid. Detection and characterization of HE ipDNA-capsids are based on two-dimensional, non-denaturing agarose gel electrophoresis, followed by structure determination with electron microscopy and protein identification with SDS-PAGE/mass spectrometry. After expulsion from HE ipDNA-capsids, ipDNA forms sharp bands during gel electrophoresis. The following hypotheses are presented: (1) T3 has evolved feedback-initiated, ATP-driven capsid contraction/hyper-expansion cycles that accelerate DNA packaging when packaging is slowed by increase in the packaging-resisting force of the ipDNA and (2) each gel electrophoretic ipDNA band reflects a contraction/hyper-expansion cycle.

Bone is a mechanosensitive tissue that adapts its mass, architecture and mechanical properties to external loading. Appropriate mechanical loads offer an effective means to stimulate bone remodeling and prevent bone loss. A role of in situ strain in bone is considered essential in enhancement of bone formation, and establishing a quantitative relationship between 3D strain distributions and a rate of local bone formation is important. Digital speckle pattern interferometry (DSPI) can achieve whole-field, non-contacting measurements of microscopic deformation for high-resolution determination of 3D strain distributions. However, the current system does not allow us to derive accurate strain distributions because of complex surface contours inherent to biological samples. Through development of a custom-made piezoelectric loading device as well as a new DSPI-based force calibration system, we built an advanced DSPI system and integrated local contour information to deformation data. Using a mouse femur in response to a knee loading modality as a model system, we determined 3D strain distributions and discussed effectiveness and limitations of the described system.

Dynamic mechanical loads have been known to stimulate bone formation. Many biophysical factors such as number of daily loading cycles, bone strain, strain-induced interstitial fluid flow, molecular transport, and modulation of intramedullary pressure have been considered as potential mediators in mechanotransduction of bone. Using a knee loading modality that enhances anabolic responses in mouse hindlimb, we addressed a question: Do oscillatory loads applied to the knee induce dynamic alteration of intramedullary pressure in the femoral medullary cavity? To answer this question, mechanical loads were applied to the knee with a custom-made piezoelectric loader and intramedullary pressure in the femoral medullary cavity was measured with a fiber optic pressure sensor. We observed that in response to sinusoidal forces of 0.5 Hz and 10 Hz, pressure amplitude increased up to 4-N loads and reached a plateau at 130 Pa. This amplitude significantly decreased with a loading frequency above 20 Hz. To confirm alteration of intramedullary pressure, real-time motion of microparticles in a glass tube inserted to the femoral medullary cavity ex vivo was visualized. Taken together, these data reveal that knee loading dynamically alters intramedullary pressure as a function of loading intensities and frequencies.

Mechanical loading is well known to stimulate bone remodeling. Load-driven interstitial fluid flow and molecular transport have been postulated to play a role in the enhancement of bone formation. In order to evaluate load-driven molecular transport in a lacunocanalicular network, we conducted fluorescence recovery after photobleaching (FRAP) experiments using lacunae stained with uranine (376 Da). Loads were applied to a mouse femur ex vivo with a novel knee-loading modality, where the distal epiphysis was loaded with a sinusoidal force at 2 Hz. The lacunae in the diaphysis located 25% (∼4 mm) proximal to the loading site were photobleached and sequentially imaged, and a time constant for fluorescence recovery was determined both with and without knee loading. The time constant was estimated as the period to recover 63% of fluorescent intensity using a best-fit exponential curve. The results reveal that the applied loads shortened the time constant from 33 ± 9 s with non-loading control to 25 ± 11 s with knee loading (p = 0.0014). The strain in the measurement site was <100 μstain along the femoral midshaft, which was an order of magnitude smaller than the minimum effective strain threshold for bone remodeling. Taken together, the current study supports the notion that molecular transport in cortical bone is enhanced by the loads applied to the epiphysis without inducing significant in situ strain in the diaphysis.

Mechanical stimulation is critical for bone architecture and bone mass. The aim of this study was to examine the effects of mechanical loads applied to the knee. The specific question was whether loads applied to the tibial epiphysis would enhance bone formation in the tibial diaphysis. In C57/BL/6 mice, loads of 0.5 N were applied for 3 min per day for 3 days at 5, 10, or 15 Hz. Bone samples were harvested 13 days after the last loading. The strains were measured 13 ± 2 μstrains at 5 Hz in the diaphysis. The histomorphometric data in the diaphysis clearly showed enhanced bone formation. First, compared with nonloaded control the cross-sectional cortical area was increased by 11% at 5 Hz and 8% at 10 Hz (both P < 0.05). Second, the cortical thickness was elevated by 12% at 5 Hz ( P < 0.01) and 8% at 10 Hz ( P < 0.05). Third, mineralizing surface (MS/BS), mineral apposition rate (MAR), and bone formation rate (BFR/BS) were increased at 5 Hz ( P < 0.01 for MS/BS; P < 0.001 for MAR and BFR/BS) and at 10 Hz ( P < 0.05 for MS/BS; P < 0.01 for MAR and BFR/BS). Bone formation was enhanced more extensively in the medial side than the lateral or the posterior side. The results reveal that knee loading is an effective means to enhance bone formation in the tibial diaphysis in a loading-frequency dependent manner without inducing significant in situ strain at the site of bone formation.

Background Bone alters its architecture and mass in response to the mechanical environment, and thus varying loading modalities have been examined for studying load-driven bone formation. The current study aimed to evaluate the anabolic effects of knee loading on diaphyseal cortical bone in the femur. Methods Using a custom-made piezoelectric loader, 0.5-N loads were laterally applied to the left knee of C57/BL/6 mice at 5, 10, 15, and 20 Hz for 3 minutes per day for 3 consecutive days. Animals were sacrificed for examination 13 days after the last loading. The contralateral femur was used as a non-loading control, and the statistical significance of loading effects was evaluated with p < 0.05. Results Although diaphyseal strains were measured as small as 12 μstrains, bone histomorphometry clearly demonstrated frequency-dependent enhancement of bone formation. Compared to a non-loading control, bone formation on the periosteal surface was significantly enhanced. The loading at 15 Hz was most effective in elevating the mineralizing surface (1.7 x; p < 0.05), mineral apposition rate (1.4 x; p < 0.001), and bone formation rate (2.4 x; p < 0.01). The loading at 10 Hz elevated the mineralizing surface (1.4 x; p < 0.05), mineral apposition rate (1.3 x; p < 0.01), and bone formation rate (1.8 x; p < 0.05). The cross-sectional cortical area and the cortical thickness in the femoral diaphysis were significantly increased by loading at 10 Hz (both 9%) and 15 Hz (12% and 13%, respectively). Conclusion The results support the anabolic effects of knee loading on diaphyseal cortical bone in the femur with small in situ strain, and they extend our knowledge on the interplay between bone and joints. Strengthening the femur contributes to preventing femoral fractures, and the discovery about the described knee loading might provide a novel strategy to strengthen osteoporotic bones. Further analyses are required to understand the biophysical and molecular mechanism behind knee loading.

Bone is a mechanosensitive tissue that adapts its mass, architecture and mechanical properties to mechanical loading. Appropriate mechanical loads provide an effective means to stimulate bone remodeling and prevent from bone loss. It is controversial whether in situ strain in bone is a critical determinant in enhancement of bone formation, and it is therefore important to evaluate load-driven strain in bone. Using electronic speckle pattern interferometry, we determined high-resolution three-dimensional strains on the mouse femur in response to two loading modalities: an axial loading modality (ALM) and a knee loading modality (KLM). We demonstrated that these two loading modalities induced a different pattern of strain distributions. ALM generated strain in the midshaft of cortical bone, while strains with KLM were concentrated on the distal epiphysis of the mouse femur. Since KLM is capable of enhancing bone formation in cortical bone distant from the knee, the current results indicate that in situ strain is not always necessary for load-driven bone formation.

As a countermeasure for bone loss experienced by astronauts during the microgravity of spaceflight, and by aging patients (e.g., osteoporosis), the designs of devices for the application of lateral loads to the knee joint are described. These "knee-loading joint supporters (KJS)" are intended to clamp onto the human knee and provide variable, intermittent pulses of mechanical load. Based on previous experimentation with mouse models, it is expected that these KJS devices will facilitate human bone strengthening.
