Stochastic rounding (SR) is a probabilistic method used to round numbers to floating-point and fixed-point representations. In length n summation, the worst-case error of SR grows as √(n) with high probability, unlike for standard modes, like round-to-nearest (RN), which grows as n. For this reason, the former is increasingly employed in large-scale, low-precision computations as an RN alternative. Additionally, SR alleviates stagnation, whereby relatively small summands are completely rounded off and do not contribute to the sum. We provide an update to [Croci et al., Roy. Soc. Open Sci. 9.3 (2022), pp. 1-25], a survey which discusses the development and use of SR between 1949 and 2022, citing over 100 references. Since then, there has been a surge of new research, and this update covers almost four years of further progress in applying, analysing, and implementing SR. Our main focus is limited-precision stochastic rounding, a new variant that fixes the precision of the random numbers used. We provide insights into industrial and numerical analysis activities surrounding SR, highlighting the next possible steps in making this rounding mode more widely available in hardware.

This work proposes a mathematically founded mixed precision accumulation strategy for the inference of neural networks. Our strategy is based on a new componentwise forward error analysis that explains the propagation of errors in the forward pass of neural networks. Specifically, our analysis shows that the error in each component of the output of a linear layer is proportional to the condition number of the inner product between the weights and the input, multiplied by the condition number of the activation function. These condition numbers can vary widely from one component to the other, thus creating a significant opportunity to introduce mixed precision: each component should be accumulated in a precision inversely proportional to the product of these condition numbers. We propose a numerical algorithm that exploits this observation: it first computes all components in low precision, uses this output to estimate the condition numbers, and recomputes in higher precision only the components associated with large condition numbers. We test our algorithm on various networks and datasets and confirm experimentally that it can significantly improve the cost–accuracy tradeoff compared with uniform precision accumulation baselines.

Many computer vision tasks use convolutional neural networks (CNNs). These networks have a significant computational cost and complex implementations, in particular on embedded systems. A common way to implement CNNs on integrated circuits is to use low-precision quantized weights and activations instead of de facto floating-point (FP) ones. This is important to reduce the implementation cost. However, this has drawbacks regarding accuracy, and Quantization-Aware Training (QAT) is one of the most popular approaches to mitigate this issue. In this article, we introduce a multiplierless-aware training approach that significantly reduces hardware resource consumption. We propose to incrementally fix weights to their current value based on their implementation cost. To compute this cost, we base our approach on a Multiple Constant Multiplication (MCM) shift-and-add solving technique. With this idea, we show a global implementation cost reduction by around 25% w. r. t. a vanilla QAT approach without hardware usage in the loop. Compared to state-of-the-art multiplierless-aware training methods, the network accuracy of our designs is closer to that of a vanilla QAT baseline.

Training Deep Neural Networks (DNNs) is computationally demanding, leading to a growing interest in reduced precision formats to enhance hardware efficiency. Several frame-works explore custom number formats with parameterizable precision through software emulation on CPUs or GPUs. However, they lack comprehensive support for different rounding modes and struggle to accurately evaluate the impact of custom precision for FPGA-based targets. This paper introduces MPTorch-FPGA, an extension of the MPTorch framework for performing custom, multi-precision inference and training computations in CPU, GPU, and FPGA environments in PyTorch. MPTorch-FPGA can generate a model-specific accelerator for DNN training, with customizable sizes and arithmetic implementations, providing bit-level accuracy with respect to emulated low precision DNN training on GPUs or CPUs. An offline matching algorithm selects one of several pre-generated (static) FPGA configurations using a custom performance model to estimate latency. To showcase the versatility of MPTorch-FPGA, we present a series of training benchmarks using diverse DNN models, exploring a range of number format configurations and rounding modes. We report both accuracy and hardware performance metrics, verifying the precision of our performance model by comparing estimated and measured latencies across multiple benchmarks. These results highlight the flexibility and practical value of our framework.

Classical probabilistic rounding error analysis is particularly well suited to stochastic rounding (SR), and it yields strong results when dealing with floating-point algorithms that rely heavily on summation. For many numerical linear algebra algorithms, one can prove probabilistic error bounds that grow as O(nu), where n is the problem size and u is the unit roundoff. These probabilistic bounds are asymptotically tighter than the worst-case ones, which grow as O(nu). For certain classes of algorithms, SR has been shown to be unbiased. However, all these results were derived under the assumption that SR is implemented exactly, which typically requires a number of random bits that is too large to be suitable for practical implementations. We investigate the effect of the number of random bits on the probabilistic rounding error analysis of SR. To this end, we introduce a new rounding mode, limited-precision SR. By taking into account the number r of random bits used, this new rounding mode matches hardware implementations accurately, unlike the ideal SR operator generally used in the literature. We show that this new rounding mode is biased and that the bias is a function of r. As r approaches infinity, however, the bias disappears, and limited-precision SR converges to the ideal, unbiased SR operator. We develop a novel model for probabilistic error analysis of algorithms employing SR. Several numerical examples corroborate our theoretical findings.

Error-tolerant applications, such as multimedia processing, machine learning, signal processing, and scientific computing, can produce satisfactory outputs even when approximate computations are performed. Approximate computing (AxC) is nowadays a well-established design and computing paradigm that produces more efficient computation systems by judiciously reducing their computation quality. AxC has been applied to arithmetic circuits, modifying their logic behavior. Depending on the approximation process, arithmetic properties, such as commutativity, are not consistently maintained. When such properties are absent, error accumulation and application outputs depend on the order in which data is processed. In this work, we show that controlling the operand order in non-commutative approximate circuits can greatly reduce computational errors. We propose SWAPPER, a lightweight approach that drastically reduces the approximation error by dynamically changing the order of the input operands using only a single bit for the decision. To explore and identify the most suitable bit for the swapping choice, we propose a framework that can be applied at different granularities, leading to large error reductions and significant accuracy improvements. Experimental results at both component and application levels show error reductions of up to 50 at the component level and more than 90 AxBench application suite.

To date, the most promising methods for 8-bit DNN training use two different floating-point formats: a 5-bit ex-ponent for greater range on gradients in the backwards pass, and a 4-bit exponent with less range but greater precision for representing weights and activations in the forward pass. Ordinarily, subnormal representations are also used to extend the range and provide gradual underflow, but subnormals require considerable special-case logic which increases the cost of area-critical operators such as multiply-accumulate units. Instead, this paper proposes to replace traditional subnormals with what we call supernormal values where mantissa bits are converted into exponent bits at both the subnormal/zero and infinity ends of the range. Hence, supernormals provide maximal range extension by sacrificing some precision at both ends. The logic required to implement supernormals is a trivial change to existing logic that processes normalised values, thus avoiding the logic overhead of subnormals while providing a larger range extension. We use the range extension provided by supernormals in new mixed-precision 8-bit formats to showcase training results that are comparable to the state-of-the-art while showing an area savings.

Training Deep Neural Networks (DNNs) can be computationally demanding, particularly when dealing with large models. Recent work has aimed to mitigate this computational challenge by introducing 8-bit floating-point (FP8) formats for multiplication. However, accumulations are still done in either half (16-bit) or single (32-bit) precision arithmetic. In this paper, we investigate lowering accumulator word length while maintaining the same model accuracy. We present a multiply-accumulate (MAC) unit with FP8 multiplier inputs and FP12 accumulations, which leverages an optimized stochastic rounding (SR) implementation to mitigate swamping errors that commonly arise during low precision accumulations. We investigate the hardware implications and accuracy impact associated with varying the number of random bits used for rounding operations. We additionally attempt to reduce MAC area and power by proposing a new scheme to support SR in floating-point MAC and by removing support for subnormal values. Our optimized eager SR unit significantly reduces delay and area when compared to a classic lazy SR design. Moreover, when compared to MACs utilizing single-or half-precision adders, our design showcases notable savings in all metrics. Furthermore, our approach consistently maintains near baseline accuracy across a diverse range of computer vision tasks, making it a promising alternative for low-precision DNN training.

Artificial Neural Networks (ANNs) appear to be one of the technological revolutions of recent human history. The capability of such systems does not come at a low cost, which led researchers to develop more and more efficient techniques to implement them. Optimization approaches have been developed, such as pruning and quantization, leading to reduced memory and computation requirements. Furthermore, such approaches are adapted to the specific hardware platform features to further increase efficiency. To improve it further, the HW programmability can be traded off in favor of more specialized custom HW ANN accelerators. In this education abstract, we illustrate how optimizing operations execution at different levels, from SW to HW, can improve the efficiency of ANN execution.

While convolutional neural networks (CNNs) have demonstrated exceptional performance in computer vision, optimizing FPGA-based CNN accelerators remains a challenge due to resource constraints. This is especially true for sequential designs, which are limited by external memory access. Despite the benefits of sparsity, most existing sparse accelerators are sequential and memory-bound. We introduce an innovative dataflow CNN architecture enriched with structured sparsity through pattern pruning at tile level. In our approach, pattern pruning serves as a fine-tuning step, effectively reducing FPGA resource consumption, including memory and logic. Experimental results indicate better latency than other dataflow approaches, while maintaining competitive accuracy compared to state-of-the-art unstructured pruning methods. We demonstrate the versatility of our approach in image classification and super-resolution applications, where we achieve a consistent 30 frames per second across a wide range of image sizes on the Set5 dataset.

Large-scale deep neural networks (DNNs) have achieved remarkable success in many application scenarios. However, high computational complexity and energy costs of modern DNNs make their deployment on edge devices challenging. Model quantization is a common approach to deal with deployment constraints, but searching for optimized bit-widths can be challenging. In this work, we present Adaptive Bit-Width Quantization Aware Training (AdaQAT), a learning-based method that automatically optimizes weight and activation signal bit-widths during training for more efficient DNN inference. We use relaxed real-valued bit-widths that are updated using a gradient descent rule, but are otherwise discretized for all quantization operations. The result is a simple and flexible QAT approach for mixed-precision uniform quantization problems. Compared to other methods that are generally designed to be run on a pretrained network, AdaQAT works well in both training from scratch and fine-tuning scenarios.Initial results on the CIFAR-10 and ImageNet datasets using ResNet20 and ResNet18 models, respectively, indicate that our method is competitive with other state-of-the-art mixed-precision quantization approaches.

This work presents two novel methods that simultaneously optimize both the design of a finite impulse response (FIR) filter and its multiplierless hardware implementation. We use integer linear programming (ILP) to minimize the number of adders used to implement a direct/transposed FIR filter adhering to a given frequency specification. The proposed algorithms work by either fixing the number of adders used to implement the products (multiplier block adders) or by bounding the adder depth (AD) used for these products. The latter can be used to design filters with minimal AD for low-power applications. In contrast to previous multiplierless FIR filter approaches, the methods introduced here ensure adder count optimality. We perform extensive numerical experiments, which demonstrate that our simultaneous filter design approach yields results that are in many cases on par or better than those in the literature.

Software implementations of mathematical functions often use approximations that can be either polynomial or rational in nature. While polynomials are the preferred approximation in most cases, rational approximations are nevertheless an interesting alternative when dealing with functions that have a pronounced "nonpolynomial behavior" (such as poles close to the approximation domain, asymptotes or finite limits at ±∞).The major challenge is that of computing good rational approximations with machine number coefficients (e.g. floating-point or fixed-point) with respect to the supremum norm, a key step in most procedures for evaluating a mathematical function. This is made more complicated by the fact that even when dealing with real-valued coefficients, optimal supremum norm solutions are sometimes difficult to obtain. Here, we introduce flexible and fast algorithms for computing such rational approximations with both real and machine number coefficients. Their effectiveness is explored on several examples.

One of the major bottlenecks in high-resolution Earth Observation (EO) space systems is the downlink between the satellite and the ground. Due to hardware limitations, on-board power limitations or ground-station operation costs, there is a strong need to reduce the amount of data transmitted. Various processing methods can be used to compress the data. One of them is the use of on-board deep learning to extract relevant information in the data. However, most ground-based deep neural network parameters and computations are performed using single-precision floating-point arithmetic, which is not adapted to the context of on-board processing. We propose to rely on quantized neural networks and study how to combine low precision (mini) floating-point arithmetic with a Quantization-Aware Training methodology. We evaluate our approach with a semantic segmentation task for ship detection using satellite images from the Airbus Ship dataset. Our results show that 6-bit floating-point quantization for both weights and activations can compete with single-precision without significant accuracy degradation. Using a Thin U-Net 32 model, only a 0.3% accuracy degradation is observed with 6-bit minifloat quantization (a 6-bit equivalent integer-based approach leads to a 0.5% degradation). An initial hardware study also confirms the potential impact of such low-precision floating-point designs, but further investigation at the scale of a full inference accelerator is needed before concluding whether they are relevant in a practical on-board scenario.

The most compute-intensive stage of deep neural network (DNN) training is matrix multiplication where the multiply-accumulate (MAC) operator is key. To reduce training costs, we consider using low-precision arithmetic for MAC operations. While low-precision training has been investigated in prior work, the focus has been on reducing the number of bits in weights or activations without compromising accuracy. In contrast, the focus in this paper is on implementation details beyond weight or activation width that affect area and accuracy. In particular, we investigate the impact of fixed- versus floating-point representations, multiplier rounding, and floating-point exceptional value support. Results suggest that (1) low-precision floating-point is more area-effective than fixed-point for multiplication, (2) standard IEEE-754 rules for subnormals, NaNs, and intermediate rounding serve little to no value in terms of accuracy but contribute significantly to area, (3) low-precision MACs require an adaptive loss-scaling step during training to compensate for limited representation range, and (4) fixed-point is more area-effective for accumulation, but the cost of format conversion and downstream logic can swamp the savings. Finally, we note that future work should investigate accumulation structures beyond the MAC level to achieve further gains.

The design and implementation of Deep Learning (DL) models is currently receiving a lot of attention from both industrials and academics. However, the computational workload associated with DL is often out of reach for low-power embedded devices and is still costly when run on datacenters. By relaxing the need for fully precise operations, Approximate Computing (AxC) substantially improves performance and energy efficiency. DL is extremely relevant in this context, since playing with the accuracy needed to do adequate computations will significantly enhance performance, while keeping the quality of results in a user-constrained range. This chapter will explore how AxC can improve the performance and energy efficiency of hardware accelerators in DL applications during inference and training.

The design and implementation of Convolutional Neural Networks (CNNs) for deep learning (DL) is currently receiving a lot of attention from both industrials and academics. However, the computational workload involved with CNNs is often out of reach for low power embedded devices and is still very costly when running on datacenters. By relaxing the need for fully precise operations, approximate computing substantially improves performance and energy efficiency. Deep learning is very relevant in this context, since playing with the accuracy to reach adequate computations will significantly enhance performance, while keeping quality of results in a user-constrained range. AdequateDL is a project aiming to explore how approximations can improve performance and energy efficiency of hardware accelerators in DL applications. This paper presents the main concepts and techniques related to approximation of CNNs and preliminary results obtained in the AdequateDL framework.

A hardware implementation can be defined to be faithful to the frequency specification of a linear time-invariant digital filter. Filter design and implementation then become a single global optimisation problem. To solve this problem, existing tools are reviewed, and the missing ones are framed.

This work presents two novel optimization methods based on integer linear programming (ILP) that minimize the number of adders used to implement a direct/transposed finite impulse response (FIR) filter adhering to a given frequency specification. The proposed algorithms work by either fixing the number of adders used to implement the products (multiplier block adders) or by bounding the adder depth (AD) used for these products. The latter can be used to design filters with minimal AD for low power applications. In contrast to previous multiplierless FIR approaches, the methods introduced here ensure adder count optimality. To demonstrate their effectiveness, we perform several experiments using established design problems from the literature, showing superior results.
