More than half of the Top 500 supercomputers employ GPUs as accelerators. On GPU-accelerated platforms, developers face a key diagnostic gap: profilers show source lines where stalls occur, but not why they occur. Furthermore, the same kernel may have different stalls and underlying causes on different GPUs. This paper presents LEO, a root-cause analyzer for NVIDIA, AMD, and Intel GPUs that performs backward slicing from stalled instructions, considering dependencies arising from registers as well as vendor-specific synchronization mechanisms. LEO attributes GPU stalls to source instructions with the goal of explaining root causes of these inefficiencies. Across 21 workloads on three GPU platforms, LEO-guided optimizations deliver geometric-mean speedups of 1.73×–1.82×. Our case studies show that (1) the same kernel may require different optimizations for different GPU architectures, and (2) LEO's structured diagnostics improve code optimization with large language models relative to code-only and raw-stall-count baselines.

The Linux Foundation’s HPCToolkit is a measurement tool that enables profiling and tracing HPC applications on heterogeneous exascale supercomputers. Using HPCToolkit, users can measure applications at scales up to thousands of GPU-accelerated compute nodes and collect fine-grained, instruction-level measurements of CPU and GPU code. However, analyzing performance measurements from such large-scale program executions can be challenging. Performance databases for exascale executions can grow to terabytes, making manual inspection using a graphical user interface difficult and time-consuming. Methods for automated and programmatic data inspection are necessary to inspect the vast measurement data and identify characteristics of interest. In this paper, we present a new approach to analyzing the performance of applications measured with HPCToolkit, with a focus on measurement data from large-scale executions. Our analysis framework provides access to HPCToolkit data with Python and analyzes it with the Pandas library. Analysis tasks can be automated, integrated, and saved inside Jupyter notebooks. When extracting data from persistent storage, users can employ techniques for automatically pruning code regions with low information content and sampling large-scale executions using specialized query expressions. We tested and evaluated our solution by analyzing executions with several thousands of profiles and traces.

As part of the US Department of Energy’s Exascale Computing Project (ECP), Rice University has been refining its HPCToolkit performance tools to better support measurement and analysis of applications executing on exascale supercomputers. To efficiently collect performance measurements of GPU-accelerated applications, HPCToolkit employs novel non-blocking data structures to communicate performance measurements between tool threads and application threads. To attribute performance information in detail to source lines, loop nests, and inlined call chains, HPCToolkit performs parallel analysis of large CPU and GPU binaries involved in the execution of an exascale application to rapidly recover mappings between machine instructions and source code. To analyze terabytes of performance measurements gathered during executions at exascale, HPCToolkit employs distributed-memory parallelism, multithreading, sparse data structures, and out-of-core streaming analysis algorithms. To support interactive exploration of profiles up to terabytes in size, HPCToolkit’s hpcviewer graphical user interface uses out-of-core methods to visualize performance data. The result of these efforts is that HPCToolkit now supports collection, analysis, and presentation of profiles and traces of GPU-accelerated applications at exascale. These improvements have enabled HPCToolkit to efficiently measure, analyze and explore terabytes of performance data for executions using as many as 64K MPI ranks and 64K GPU tiles on ORNL’s Frontier supercomputer. HPCToolkit’s support for measurement and analysis of GPU-accelerated applications has been employed to study a collection of open-science applications developed as part of ECP. This paper reports on these experiences, which provided insight into opportunities for tuning applications, strengths and weaknesses of HPCToolkit itself, as well as unexpected behaviors in executions at exascale.

Finite-difference methods based on high-order stencils are widely used in seismic simulations, weather forecasting, computational fluid dynamics, and other scientific applications. Achieving HPC-level stencil computations on one architecture is challenging, porting to other architectures without sacrificing performance requires significant effort, especially in this golden age of many distinctive architectures. To help developers achieve performance, portability, and productivity with stencil computations, we developed StencilPy. With StencilPy, developers write stencil computations in a high-level domain-specific language, which promotes productivity, while its backends generate efficient code for existing and emerging architectures, including modern many-core CPUs (such as AMD Genoa-X, Fujitsu A64FX, and Intel Sapphire Rapids), latest generations of GPUs (including NVIDIA H100 and A100, AMD MI200, and Intel Ponte Vecchio), and accelerators (including Cerebras and STX). StencilPy demonstrates promising performance results on par with hand-written code, maintains cross-architectural performance portability, and enhances productivity. Its modular design enables easy configuration, customization, and extension. A 25-point star-shaped stencil written in StencilPy is one-quarter of the length of a hand-crafted CUDA code and achieves similar performance on an NVIDIA H100 GPU. In addition, the same kernel written using our tool is 7x shorter than hand-optimized code written in Cerebras Software Language (CSL), and it delivers comparable performance that code on a Cerebras CS-2.

Finite-difference methods based on high-order stencils are widely used in seismic simulations, weather forecasting, and computational fluid dynamics. Recently, multiple research groups have begun exploring the use of dataflow architectures, such as Cerebras' wafer-scale engine, to accelerate stencil computations. However, implementations of stencil computations for dataflow architectures must address unique challenges, such as managing the routing of data communications and accommodating a significantly constrained memory footprint. These make hand-crafting code for a dataflow architecture difficult and time-consuming. This paper describes a framework for developing portable, high-performance implementations of stencil computations for modern node architectures. The paper focuses on code generation strategies for the Cerebras wafer-scale engine, including code generation of router configurations and sequencing of communication for high-order stencils. A 25-point star-shaped stencil written using our tool is 7x shorter than handcrafted code written in Cerebras Software Language (CSL), and it delivers comparable performance to manually written code.

Fast and accurate numerical simulations are crucial for designing large-scale geological carbon storage projects ensuring safe long-term CO2 containment as a climate change mitigation strategy. These simulations involve solving numerous large and complex linear systems arising from the implicit Finite Volume (FV) discretization of PDEs governing subsurface fluid flow. Compounded with highly detailed geomodels, solving linear systems is computationally and memory expensive, and accounts for the majority of the simulation time. Modern memory hierarchies are insufficient to meet the latency and bandwidth needs of large-scale numerical simulations. Therefore, exploring algorithms that can leverage alternative and balanced paradigms such as dataflow and in-memory computing is crucial. This work introduces a matrix-free algorithm to solve FV-based linear systems using a dataflow architecture to significantly minimize memory latency and bandwidth bottlenecks. Our implementation achieves two orders of magnitude speedup compared to a GPGPU-based reference implementation, and up to 1.2 PFlops on a single dataflow device.

Large Language Models show great potential in generating and optimizing code. Widely used sampling methods such as Nucleus Sampling increase the diversity of generation but often produce repeated samples for low temperatures and incoherent samples for high temperatures. We present Priority Sampling, a simple and deterministic sampling technique that produces unique samples ordered by the model's confidence. Additionally, Priority Sampling supports a controllable and structured exploration process using regular-expression-based generation. Priority Sampling outperforms Nucleus Sampling for any number of samples, boosting the performance of the original model from 2.87% to 5% improvement over -Oz. Moreover, it outperforms the autotuner used to generate training labels of the original model in just 30 samples.

PDE discretization schemes yielding stencil-like computing patterns are commonly used for seismic modeling, weather forecast, and other scientific applications. Achieving HPC-level stencil computations on one architecture is challenging, porting to other architectures without sacrificing performance requires significant effort, especially in this golden age of many distinctive architectures. To help developers achieve performance, portability, and productivity with stencil computations, we developed StencilPy. With StencilPy, developers write stencil computations in a high-level domain-specific language, which promotes productivity, while its backends generate efficient code for existing and emerging architectures, including NVIDIA, AMD, and Intel GPUs, A64FX, and STX. StencilPy demonstrates promising performance results on par with hand-written code, maintains cross-architectural performance portability, and enhances productivity. Its modular design enables easy configuration, customization, and extension. A 25-point star-shaped stencil written in StencilPy is one-quarter of the length of a hand-crafted CUDA code and achieves similar performance on an NVIDIA H100 GPU.

Advanced compiler technology is crucial for enabling machine learning applications to run on novel hardware, but traditional compilers fail to deliver performance, popular auto-tuners have long search times and expert-optimized libraries introduce unsustainable costs. To address this, we developed LoopTune, a deep reinforcement learning compiler that optimizes tensor computations in deep learning models for the CPU. LoopTune optimizes tensor traversal order while using the ultra-fast lightweight code generator LoopNest to perform hardware-specific optimizations. With a novel graph-based representation and action space, LoopTune speeds up LoopNest by 3.2x, generating an order of magnitude faster code than TVM, 2.8x faster than MetaSchedule, and 1.08x faster than AutoTVM, consistently performing at the level of the hand-tuned library Numpy. Moreover, LoopTune tunes code in order of seconds.

As we near the end of Moore's law scaling, the next-generation computing platforms are increasingly exploring heterogeneous processors for acceleration. Graphics Processing Units (GPUs) are the most widely used accelerators. Meanwhile, applications are evolving by adopting new programming models and algorithms for emerging platforms. To harness the full power of GPUs, performance tools serve a critical role in understanding and tuning application performance, especially for those that involve complex executions spanning both CPU and GPU. To help developers analyze and tune applications, performance tools need to associate performance metrics with calling contexts. However, existing performance tools incur high overhead collecting and attributing performance metrics to full calling contexts. To address the problem, we developed a tool that constructs both CPU and GPU calling contexts with low overhead and high accuracy. With an innovative call path memoization mechanism, our tool can obtain call paths for GPU operations with negligible cost. For GPU calling contexts, our tool uses an adaptive epoch profiling method to collect GPU instruction samples to reduce the synchronization cost and reconstruct the calling contexts using postmortem analysis. We have evaluated our tool on nine HPC and machine learning applications on a machine equipped with an NVIDIA GPU. Compared with the state-of-the-art GPU profilers, our tool reduces the overhead for coarse-grained profiling of GPU operations from 2.07X to 1.42X and the overhead for fine-grained profiling of GPU instructions from 27.51X to 4.61X with an accuracy of 99.93% and 96.16% in each mode.

Finite-difference methods based on high-order stencils are commonly used for modeling of seismic wave propagation, weather forecasting, computational fluid dynamics, convolutional neural networks, and others. Nowadays, the community commonly employs graphics processing units (GPUs) to accelerate such stencil computations. As a result, knowing how to write efficient stencil computations for GPUs is of significant interest. While high-performance, low-order stencils on GPUs have been studied extensively in the literature, not all proposed approaches work well for high-order stencils. Furthermore, coping with boundary conditions used with stencils for seismic modeling makes it challenging to efficiently exploit thread-level parallelism on GPUs. In this article, we describe several implementations of a 25-point stencil. We evaluate our stencil code shapes, memory hierarchy usage, data access patterns, and other performance attributes on several modern GPUs and compare them with machine rooflines. On average, our top-performing kernels achieve six times the performance of a 25-point stencil code developed in C and mapped to GPUs using OpenACC. Several of our implementations have excellent performance portability across multiple generations of both NVIDIA and AMD GPUs.

General-purpose GPUs have become common in modern computing systems to accelerate applications in many domains, including machine learning, high-performance computing, and autonomous driving. However, inefficiencies abound in GPU-accelerated applications, which prevent them from obtaining bare-metal performance. Performance tools play an important role in understanding performance inefficiencies in complex code bases. Many GPU performance tools pinpoint time-consuming code and provide high-level performance insights but overlook one important performance issue---value-related inefficiencies, which exist in many GPU code bases. In this paper, we present ValueExpert, a novel tool to pinpoint value-related inefficiencies in GPU applications. ValueExpert monitors application execution to capture values produced and used by each load and store operation in GPU kernels, recognizes multiple value patterns, and provides intuitive optimization guidance. We address systemic challenges in collecting, maintaining, and analyzing voluminous performance data from many GPU threads to make ValueExpert applicable to complex applications. We evaluate ValueExpert on a wide range of well-tuned benchmarks and applications, including PyTorch, Darknet, LAMMPS, Castro, and many others. ValueExpert is able to identify previously unknown performance issues and provide suggestions for nontrivial performance improvements with typically less than five lines of code changes. We verify our optimizations with application developers and upstream fixes to their repositories.

Architectures for High-Performance Computing (HPC) now commonly employ accelerators such as Graphics Processing Units (GPUs). High-level programming abstractions for accelerated computing include OpenMP as well as RAJA and Kokkos—programming abstractions based on C++ templates. Such programming models hide GPU architectural details and generate sophisticated GPU code organized as many small procedures. For example, a dot product kernel expressed using RAJA atop NVIDIA’s thrust templates yields 35 procedures. Existing performance tools are ill-suited for analyzing such complex kernels because they lack a comprehensive profile view. At best, tools such as NVIDIA’s nvvp provide a profile view that shows only limited CPU calling contexts and omits both calling contexts and loops in GPU code. To address this problem, we extended Rice University’s HPCToolkit to build a complete profile view for GPU-accelerated applications.

The OpenMP 5 standard defines OMPT-an application programming interface for tools that includes a set of introspection routines. At any point in time, a sampling-based performance tool may invoke these introspection routines from a signal handler to inquire about the nesting of parallel and task regions. Unfortunately, the OpenMP 5 standard doesn't precisely specify what one may observe with these routines when monitoring a program as it executes nested parallel regions. To address this shortcoming, we propose that the OpenMP standard require that an OpenMP implementation supports introspection consistency. This paper defines introspection consistency, describes why tools need it, and explains a novel strategy for implementing it using wait-free coordination between an OpenMP implementation and its OMPT introspection routines. We describe an implementation of this technique in the LLVM OpenMP runtime and evaluate the runtime overhead of supporting introspection consistency in LLVM OpenMP using a microbenchmark for nested parallel regions and SPEC OMP2012.

Performance tools for emerging heterogeneous exascale platforms must address two principal challenges when analyzing execution measurements. First, measurement of large-scale executions may record mountains of performance data. Second, performance measurements for parallel programs are sparse in two ways: the set of metrics present for any context and the set of contexts present in different threads. For GPU-accelerated applications, an important source of sparsity is that none of the myriad of GPU metrics apply to any of the many CPU contexts. To address these challenges, we developed a novel streaming aggregation approach to postmortem analysis that employs both shared and distributed memory parallelism to aggregate sparse performance measurements from every rank, thread, and GPU stream of an application, and attributes heterogeneous call path profiles and traces to source code. Using the same amount of resources, our approach analyzes large-scale performance measurements of GPU-accelerated applications over an order of magnitude faster than HPCToolkit and its sparse analysis results are as much as three orders of magnitude smaller than HPC-Toolkit's dense representation of metrics.

Graphics Processing Units (GPUs) have become a key technology for accelerating node performance in supercomputers, including the US Department of Energy’s forthcoming exascale systems. Since the execution model for GPUs differs from that for conventional processors, applications need to be rewritten to exploit GPU parallelism. Performance tools are needed for such GPU-accelerated systems to help developers assess how well applications offload computation onto GPUs.In this paper, we describe extensions to Rice University’s HPC-Toolkit performance tools that support measurement and analysis of Intel’s DPC++ programming model for GPU-accelerated systems atop an implementation of the industry-standard OpenCL framework for heterogeneous parallelism on Intel GPUs. HPCToolkit supports three techniques for performance analysis of programs atop OpenCL on Intel GPUs. First, HPC-Toolkit supports profiling and tracing of OpenCL kernels. Second, HPCToolkit supports CPU-GPU blame shifting for OpenCL kernel executions—a profiling technique that can identify code that executes on one or more CPUs while GPUs are idle. Third, HPCToolkit supports fine-grained measurement, analysis, and attribution of performance metrics to OpenCL GPU kernels, including instruction counts, execution latency, and SIMD waste. The paper describes these capabilities and then illustrates their application in case studies with two applications that offload computations onto Intel GPUs.

Developing efficient GPU kernels can be difficult because of the complexity of GPU architectures and programming models. Existing performance tools only provide coarse-grained tuning advice at the kernel level, if any. In this paper, we describe GPA, a performance advisor for NVIDIA GPUs that suggests potential code optimizations at a hierarchy of levels, including individual lines, loops, and functions. To relieve users of the burden of interpreting performance counters and analyzing bottlenecks, GPA uses data flow analysis to approximately attribute measured instruction stalls to their root causes and uses information about a program's structure and the GPU to match inefficiency patterns with optimization strategies. To quantify the potential benefits of each optimization strategy, we developed PC sampling-based performance models to estimate its speedup. Our experiments with benchmarks and applications show that GPA provides insightful reports to guide performance optimization. Using GPA, we obtained speedups on a Volta V100 GPU ranging from 1.01 x to 3.58 ×, with a geometric mean of 1.22 x.

Binary code analysis is widely used to assess a program's correctness, performance, and provenance. Binary analysis applications often construct control flow graphs, analyze data flow, and use debugging information to understand how machine code relates to source lines, inlined functions, and data types. To date, binary analysis has been single-threaded, which is too slow for applications such as performance analysis and software forensics, where it is becoming common to analyze binaries that are gigabytes in size and in large batches that contain thousands of binaries. This paper describes our design and implementation for accelerating the task of constructing control flow graphs (CFGs) from binaries with multithreading. Existing research focuses on addressing challenging code constructs encountered during constructing CFGs, including functions sharing code, jump table analysis, non-returning functions, and tail calls. However, existing analyses do not consider the complex interactions between concurrent analysis of shared code, making it difficult to extend existing serial algorithms to be parallel. A systematic methodology to guide the design of parallel algorithms is essential. We abstract the task of constructing CFGs as repeated applications of several core CFG operations regarding to creating functions, basic blocks, and edges. We then derive properties among CFG operations, including operation dependency, commutativity, monotonicity. These operation properties guide our design of a new parallel analysis for constructing CFGs. We achieved as much as 25$\times$ speedup for constructing CFGs on 64 hardware threads. Binary analysis applications are significantly accelerated with the new parallel analysis: we achieve 8$\times$ for a performance analysis tool and 7$\times$ for a software forensic tool with 16 hardware threads.
