PROGRAM PRODUCT FOR EFFICIENT RAY _ u _ RelChl, M., Dunger, R., Sch1eWe,A., Klemmer, T., Hartleb, M., LUX, C., Frohlich, B., GPU-based Ray Tracing of Dynamic Scenes , Pro ceedings 5. Workshop ,,Virtuelle and ErWeiterte Realitat der GI (75) Inventors: Johannes Hanika, Ulm (DE); Fachgruppe VIUAR, pp, 245-260, 2008* Alexander Keller, Berlin (DE); Peter Schroder and Steven Drucker. A data parallel algorithm for Hendrik Lensch’ Blaustein (DE) raytracing of heterogeneous databases. In Proceedings of Computer Graphics Interface, 1992, p. 167-175.* Christensen P., Fong J ., Laur D., Batali D.: Ray tracing for the movie (73) Assignee: NVIDIA Corporation, Santa Clara, CA ‘Cars’. In Proc. 2006 IEEE Symposium on Interactive Ray Tracing (Us) (2006), pp. 73-78.* Lauterbach C., Yoon S.-E., Tang M., Manocha D.: ReduceM: Inter active and memory ef?cient ray tracing of large models. Computer ( * ) Notice: Subject to any disclaimer, the term ofthis Graphics Forum 27, 4 (2008), 1313-1321.).* _ _ _ patent is extended or adjusted under 35 gbpanémemi A Keller, (‘:‘ImPmVlPg Ray Trac2lglg3 lprglgéséo?li ject pace ntersectron omputatron,” rt, pp. , U'S'C' 15403) by 960 days‘ Symposium on Interactive Ray Tracing, 2006.* Solomon Boulos, Ingo Wald and Carsten Benthin, Adaptive Ray (21) App1_ NO; 12/464,354 Packet Reordering, Proceedings of IEEE Symposium on Interactive Ray Tracing 2008* Budge, B. et al., “Out-of-core Data Management for Path Tracing on (22) Filed: May 12, 2009 Hybrid Resources,” Computer Graphics Forum, Proceedings of Eurographics, 2009, vol. 28, No. 2.

We present a novel anisotropic sampling algorithm for image space shading which builds upon recent advancements in decoupled sampling for stochastic rasterization pipelines. First, we analyze the frequency content of a pixel in the presence of motion and defocus blur. We use this analysis to derive bounds for the spectrum of a surface defined over a two-dimensional and motion-aligned shading space. Second, we present a simple algorithm that uses the new frequency bounds to reduce the number of shaded quads and the size of decoupling cache respectively by 2X and 16X, while largely preserving image detail and minimizing additional aliasing.

Current GPUs perform a significant amount of redundant shading when surfaces are tessellated into small triangles. We address this inefficiency by augmenting the GPU pipeline to gather and merge rasterized fragments from adjacent triangles in a mesh. This approach has minimal impact on output image quality, is amenable to implementation in fixed-function hardware, and, when rendering pixel-sized triangles, requires only a small amount of buffering to reduce overall pipeline shading work by a factor of eight. We find that a fragment-shading pipeline with this optimization is competitive with the REYES pipeline approach of shading at micropolygon vertices and, in cases of complex occlusion, can perform up to two times less shading work.

Occlusion culling using a traditional hierarchical depth buffer, or z-pyramid, is less effective when rendering with motion blur. We present a new data structure, the tz-pyramid, that extends the traditional z-pyramid to represent scene depth values in time. This temporal information improves culling efficacy when rendering with motion blur. The tz-pyramid allows occlusion culling to adapt to the amount of scene motion, providing a balance of high efficacy with large motion and low cost in terms of depth comparisons when motion is small. Compared to a traditional z-pyramid, using the tz-pyramid for occlusion culling reduces the number of micropolygons shaded by up to 3.5x. In addition to better culling, the tz-pyramid reduces the number of depth comparisons by up to 1.4x.

Ray tracing has long been a method of choice for off-line rendering, but traditionally was too slow for interactive use. With faster hardware and algorithmic improvements this has recently changed, and real-time ray tracing is finally within reach. However, real-time capability also opens up new problems that do not exist in an off-line environment. In particular real-time ray tracing offers the opportunity to interactively ray trace moving/animated scene content. This presents a challenge to the data structures that have been developed for ray tracing over the past few decades. Spatial data structures crucial for fast ray tracing must be rebuilt or updated as the scene changes, and this can become a bottleneck for the speed of ray tracing. This bottleneck has recently received much attention by researchers and that has resulted in a multitude of different algorithms, data structures and strategies for handling animated scenes. The effectiveness of techniques for ray tracing dynamic scenes vary dramatically depending on details such as scene complexity, model structure, type of motion and the coherency of the rays. Consequently, there is so far no approach that is best in all cases, and determining the best technique for a particular problem can be a challenge. In this State of the Art Report (STAR), we aim to survey the different approaches to ray tracing animated scenes, discussing their strengths and weaknesses, and their relationship to other approaches. The overall goal is to help the reader choose the best approach depending on the situation, and to expose promising areas where there is potential for algorithmic improvements.

We present DIAGSPLIT, a parallel algorithm for adaptively tessellating displaced parametric surfaces into high-quality, crack-free micropolygon meshes. DIAGSPLIT modifies the split-dice tessellation algorithm to allow splits along non-isoparametric directions in the surface's parametric domain, and uses a dicing scheme that supports unique tessellation factors for each subpatch edge. Edge tessellation factors are computed using only information local to subpatch edges. These modifications allow all subpatches generated by DIAGSPLIT to be processed independently without introducing T-junctions or mesh cracks and without incurring the tessellation overhead of binary dicing. We demonstrate that DIAGSPLIT produces output that is better (in terms of image quality and number of micropolygons produced) than existing parallel tessellation schemes, and as good as highly adaptive split-dice implementations that are less amenable to parallelization.

Designed for computer graphics, oRGB is a new color model based on opponent color theory. It works well for both HSV-style color selection and computational applications such as color transfer. oRGB also enables new applications such as a quantitative cool-to-warm metric, intuitive color manipulation and variations, and simple gamut mapping.

Current GPUs rasterize micropolygons (polygons approximately one pixel in size) inefficiently. We design and analyze the costs of three alternative data-parallel algorithms for rasterizing micropolygon workloads for the real-time domain. First, we demonstrate that efficient micropolygon rasterization requires parallelism across many polygons, not just within a single polygon. Second, we produce a data-parallel implementation of an existing stochastic rasterization algorithm by Pixar, which is able to produce motion blur and depth-of-field effects. Third, we provide an algorithm that leverages interleaved sampling for motion blur and camera defocus. This algorithm outperforms Pixar's algorithm when rendering objects undergoing moderate defocus or high motion and has the added benefit of predictable performance.

We introduce GRAMPS, a programming model that generalizes concepts from modern real-time graphics pipelines by exposing a model of execution containing both fixed-function and application-programmable processing stages that exchange data via queues. GRAMPS allows the number, type, and connectivity of these processing stages to be defined by software, permitting arbitrary processing pipelines or even processing graphs. Applications achieve high performance using GRAMPS by expressing advanced rendering algorithms as custom pipelines, then using the pipeline as a rendering engine. We describe the design of GRAMPS, then evaluate it by implementing three pipelines, that is, Direct3D, a ray tracer, and a hybridization of the two, and running them on emulations of two different GRAMPS implementations: a traditional GPU-like architecture and a CPU-like multicore architecture. In our tests, our GRAMPS schedulers run our pipelines with 500 to 1500KB of queue usage at their peaks.

While contemporary approaches to SIMD ray tracing typically rely on traversing packets of coherent rays through a binary data structure, we instead evaluate the alternative of traversing individual rays through a bounding volume hierarchy with a branching factor of 16. Though obviously less efficient than high-performance packet techniques for primary rays, we demonstrate that for less coherent secondary ray distributions this approach is at least competitive with (and often faster than) typical packet traversal techniques.

Modern high-performance ray tracers use large ray packets and SIMD instruction sets to decrease both the computational and bandwidth cost compared to a single ray implementation. Current global illumination renderers, however, are still based around single ray implementations and interfaces. The presumption is that while packets have been shown to work well for highly coherent rays, in the presence of less coherent secondary ray distributions the gains of both packet and SIMD techniques dwindle rapidly. With low enough coherence, performance can be reduced to being as slow as reasonable single ray code - if not worse - so the benefit of packets for a global illumination system is assumed to be next to none. With SIMD width expanding in future architectures, leaving SIMD units underutilized means a massive loss in performance compared to the maximum performance achievable. In this paper, we present a method for recovering packet and SIMD coherence for incoherent secondary ray distributions through demand-driven reordering of rays into more coherent packets. We demonstrate that the reordering overhead is outweighed by the increased coherence within a prototypical implementation in the Manta realtime ray tracer among a wide variety of ray distributions, including diffuse path tracing.

Some computer graphics applications, such as architectural design, generate visually realistic images of computer models. This is accomplished by either explicitly or implicitly solving the light transport equations. Accurate solutions involve high-dimensional equations, and Monte Carlo (MC) techniques are used with an emphasis on importance sampling rather than stratification. For many applications, approximate solutions are adequate, and the dimensionality of the problem can be reduced. In these cases, the distribution of samples is important, and quasi-Monte Carlo (QMC) methods are often used. It is still unknown what sampling schemes are best for these lower dimensional graphics problems, or what “best” even means in this case. This paper reviews the work in MC and QMC computer graphics, and poses some open problems in the field.

Ray tracing is a technique used for generating highly realistic computer graphics images. In this paper, we explore the design of a simple but extremely parallel, multi-threaded, multi-core processor architecture that performs real-time ray tracing. Our architecture, called TRaX for Threaded Ray eXecution, consists of a set of thread states that include commonly used functional units for each thread and share large functional units through a programmable interconnect to maximize utilization. The memory system takes advantage of the application's read-only access to the scene database and write-only access to the frame buffer output to provide efficient data delivery with a relatively simple structure. Preliminary results indicate that a multi-core version of the architecture running at a modest speed of 500 MHz already provides real-time ray traced images for scenes of a complexity found in video games. We also explore the architectural impact of a ray tracer that uses procedural (computed) textures rather than image-based (look-up) textures to trade computation for reduced memory bandwidth.

We prefilter occlusion of aggregate geometry, e.g., foliage or hair, storing local occlusion as a directional opacity in each node of a bounding volume hierarchy (BVH). During intersection, we terminate rays early at BVH nodes based on ray differential, and composite the stored opacities. This makes intersection cost independent of geometric complexity for rays with large differentials, and simultaneously reduces the variance of occlusion estimates. These two algorithmic improvements result in significant performance gains for soft shadows and ambient occlusion. The prefiltered opacity data depends only on geometry, not lights, and can be computed in linear time based on assumptions about the statistics of aggregate geometry.
