This paper explores the use of don't cares in software synthesis for embedded systems. Embedded systems have extremely tight real-time and code/data size constraints, that make expensive optimizations desirable. We propose applying BDD minimization techniques in the presence of a don't care set to synthesize code for extended Finite State Machines from a BDD-based representation of the FSM transition function. The don't care set can be derived from local analysis (such as unused state codes or don't care inputs) as well as from external information (such as impossible input patterns). We show experimental results discuss their implications, the interaction between BDD-based minimization and dynamic variable reordering, and propose directions for future work.

Several algorithms for gate-level sequential circuit optimization have been reported in the literature. They perform operations similar to those in the more mature multilevel combinational domain while taking relationships across several time periods into account. These techniques are heuristic and their application ad hoc: there is no guarantee of optimality. We present a technique for producing an optimum two-level acyclic sequential circuit. While the circuit restrictions and cost function are limiting, the guarantee of optimality is novel and illuminating. The technique presented herein is useful for optimizing sub-circuits of a multilevel sequential circuit just as two-level combinatorial techniques have been in the combinational domain. Furthermore, the algorithm can be used to detect precisely circuits in which logic sharing across latch boundaries is actually possible- a hitherto unsolved problem

A description is given of SIS, an interactive tool for synthesis and optimization of sequential circuits. Given a state transition table or a logic-level description of a sequential circuit, SIS produces an optimized net-list in the target technology while preserving the sequential input-output behavior. Many different programs and algorithms have been integrated into SIS, allowing the user to choose among a variety of techniques at each stage of the process. It is built on top of MISII and includes all (combinational) optimization techniques therein as well as many enhancements. SIS serves as both a framework within which various algorithms can be tested and compared and as a tool for automatic synthesis and optimization of sequential circuits.< >

SIS is an interactive tool for synthesis and optimization of sequential circuits. Given a state transition table, a signal transition graph, or a logic-level description of a sequential circuit, it produces an optimized net-list in the target technology while preserving the sequential input-output behavior. Many different programs and algorithms have been integrated into SIS, allowing the user to choose among a variety of techniques at each stage of the process. It is built on top of MISII [5] and includes all (combinational) optimization techniques therein as well as many enhancements. SIS serves as both a framework within which various algorithms can be tested and compared, and as a tool for automatic synthesis and optimization of sequential circuits. This paper provides an overview of SIS. The first part contains descriptions of the input specification, STG (state transition graph) manipulation, new logic optimization and verification algorithms, ASTG (asynchronous signal transition graph) manipulation, and synthesis for PGA’s (programmable gate arrays). The second part contains a tutorial example illustrating the design process using SIS.

A technique is proposed for optimizing a sequential network by moving the registers to the boundary of the network using an extension of retiming, resynthesizing the combinational logic between the registers using existing logic minimization techniques, and replacing the registers throughout the network using retiming algorithms. A sliding-window optimization technique that considers a large number of different combinational blocks is proposed and demonstrated. The theoretical formulation and results on which the approach is based are given.< >
