The need to solve high-complexity problems using large-scale tightly coupled computing (that is, supercomputing) continues to grow. In this article, we address the needs, challenges, and opportunities for supercomputing over the next decade.

Dragonfly-based networks are an extensively deployed network topology in large-scale high-performance computing due to their cost-effectiveness and efficiency. The US will soon have three Exascale supercomputers for leadership class workloads deployed using dragonfly networks. Compared to indirect networks of similar scale, the dragonfly network has considerably reduced cable lengths, cable counts, and switch counts, resulting in significant network cost savings for a given system size, however, these cost reductions result in reduced global minimal paths and more challenging routing. Additionally, large scale dragonfly networks often require a taper at the global link level, resulting in less bisection bandwidth than is achievable in other traditional non-blocking topologies of equivalent scale. While dragonfly networks have been extensively studied, they have yet to be fully evaluated in an extreme scale (i.e., exascale) system that targets capability workloads. In this paper, we present the results of the first large scale evaluation of a dragonfly network on an exascale system (Frontier) and compare its behavior to a similar scale fat-tree network on a previous generation TOP500 system (Summit). This evaluation aims to determine the effect of network cost optimizations by measuring a tapered topology's impact on capability workloads. Our evaluation is based on a collection of synthetic micro-benchmarks, mini-apps, and full scale applications. It compares the scaling efficiencies of each benchmark between the dragonfly-based Frontier and the fat-tree-based Summit systems. Our results show that a dragonfly network is similar to 30% more cost efficient than a fat-tree topology, which amortizes to similar to 3% of an exascale system cost. Furthermore, while tapered dragonfly networks impose significant tradeoffs, the impacts are not as broad as initially thought and are mostly seen in applications with global communication patterns, particularly all-to-all (e.g., FFT-based algorithms), but also local communication patterns (e.g., nearest-neighbor algorithms) that are sensitive to network performance variability.

High-bandwidth storage tiers are becoming more common for their capability to absorb high-rate, bursty I/Os. Notably, the designs of these fast storage tiers differ from system to system. The variation of these layers and non-uniform methods of access can pose challenges for applications seeking to run at multiple HPC facilities. Therefore, in this work, we present Spectral, a rapid-output abstraction library to accelerate application, bulk-synchronous writes on HPC systems. We design Spectral to enable applications to use high-bandwidth storage, such as node-local storage and distributed, write-caches (e.g., burst buffers) transparently without requiring modifications to the application or file system source code. The key idea is to allow applications to spend most of the time performing productive work and to not require any source code changes for maximum portability on different HPC architectures. Spectral internally re-routes write-only files through available, high-performance I/O resources before ultimately migrating them to the shared global parallel file system. For instance, on Summit, Spectral transparently places application outputs on node-local storage and then utilizes asynchronous migration to the center-wide GPFS file system. We evaluate Spectral on the Summit HPC system (1024 nodes) using the IOR benchmark and real scientific applications. Spectral shows linear performance scaling, improving application write performance by over an order of magnitude when compared to GPFS.

In this paper, we address the challenges in achieving sustainable data-driven efficiency by providing a detailed exploration of the end-to-end operational data analytics (ODA) framework that evolved through two generations of supercomputer systems at the Oak Ridge Leadership Computing Facility (OLCF). This framework addresses large data streams ingested from heavily instrumented HPC environment that accumulates multi-terabytes per day. We outline the multifaceted data life cycle across HPC procurement, operations, and research & development, identifying key obstacles and design decisions that shape effective strategies in building and supporting data pipelines end-to-end. By sharing key insights and lessons learned from our experience, we offer recommendations for the HPC community on enabling sustainable operational data analytics and beyond. Our contributions aim to bridge the gap between potential and real benefits of operational data, guiding future efforts towards integrated and sustainable operational intelligence in high-performance computing environments.

As computing systems approach the limits of traditional silicon technology, the diminishing returns in performance per watt present a significant barrier to sustaining growth in HPC. From a large-scale scientific supercomputing facility point of view, we propose a multifaceted strategy toward specialized hardware and architectures that are optimized for energy efficiency in specific applications. We also emphasize the need for integrating energy-aware practices across all levels of HPC, from system design and software development to operational policies. We discuss strategic opportunities such as the adoption of application-specific accelerators, the development of energy-efficient algorithms, and the implementation of data-driven operational analytics. Our goal is to develop a comprehensive roadmap ensuring that future leadership systems at OLCF can meet scientific demands while operating within stringent energy budgets, thereby supporting sustainable computing growth.

A federated instrument-to-edge-to-center architecture is needed to autonomously collect, transfer, store, process, curate, and archive scientific data and reduce human-in-the-loop needs with (a) common interfaces to leverage community and custom software, (b) pluggability to permit adaptable solutions, reuse, and digital twins, and (c) an open standard to enable adoption by science facilities world-wide. The Selfdriven Experiments for Science/Interconnected Science Ecosystem (INTERSECT) Open Architecture enables science breakthroughs using intelligent networked systems, instruments and facilities with autonomous experiments, “self-driving” laboratories, smart manufacturing and artificial intelligence (AI) driven design, discovery and evaluation. It creates an open federated architecture for the laboratory of the future using a novel approach, consisting of (1) science use case design patterns, (2) a system of systems architecture, and (3) a microservice architecture.

Oak Ridge National Laboratory (ORNL)'s Self-driven Experiments for Science / Interconnected Science Ecosystem (INTERSECT) architecture project, titled "An Open Federated Architecture for the Laboratory of the Future", creates an open federated hardware/software architecture for the laboratory of the future using a novel system of systems (SoS) and microservice architecture approach, connecting scientific instruments, robot-controlled laboratories and edge/center computing/data resources to enable autonomous experiments, "self-driving" laboratories, smart manufacturing, and artificial intelligence (AI)-driven design, discovery and evaluation.The architecture project is divided into three focus areas: design patterns; SoS architecture; and microservices architecture. The design patterns area focuses on describing science use cases as design patterns that identify and abstract the involved hardware/software components and their interactions in terms of control, work and data flow. The SoS architecture area focuses on an open architecture specification for the federated ecosystem that clarifies terms, architectural elements, the interactions between them and compliance. The microservices architecture describes blueprints for loosely coupled microservices, standardized interfaces, and multi-programming language support.This document is the SoS Architecture specification only, and captures the system of systems architecture design for the INTERSECT Initiative and its components. It is intended to provide a deep analysis and specification of how the INTERSECT platform will be designed, and to link the scientific needs identified across disciplines with the technical needs involved in the support, development, and evolution of a science ecosystem.This working document reflects current discussions and design activity among the authors. The authors have worked to eliminate significant inconsistencies in publicly available versions. Comments from readers are welcome as we continue to evolve this document and the INTERSECT SoS design it describes.

As the US Department of Energy (DOE) computing facilities began deploying petascale systems in 2008, DOE was already setting its sights on exascale. In that year, DARPA published a report on the feasibility of reaching exascale. The report authors identified several key challenges in the pursuit of exascale including power, memory, concurrency, and resiliency. That report informed the DOE's computing strategy for reaching exascale. With the deployment of Oak Ridge National Laboratory's Frontier supercomputer, we have officially entered the exascale era. In this paper, we discuss Frontier's architecture, how it addresses those challenges, and describe some early application results from Oak Ridge Leadership Computing Facility's Center of Excellence and the Exascale Computing Project.

As the US Department of Energy (DOE) computing facilities began deploying petascale systems in 2008, DOE was already setting its sights on exascale. In that year, DARPA published a report on the feasibility of reaching exascale. The report authors identified several key challenges in the pursuit of exascale including power, memory, concurrency, and resiliency. That report informed the DOE's computing strategy for reaching exascale. With the deployment of Oak Ridge National Laboratory's Frontier supercomputer, we have officially entered the exascale era. In this paper, we discuss Frontier's architecture, how it addresses those challenges, and describe some early application results from Oak Ridge Leadership Computing Facility's Center of Excellence and the Exascale Computing Project.

Scientific communities are increasingly adopting deep learning (DL) models in their applications to accelerate scientific discovery processes. However, with rapid growth in the computing capabilities of HPC supercomputers, large-scale DL applications have to spend a significant portion of training time performing I/O to a parallel storage system. Previous research works have investigated optimization techniques such as prefetching and caching. Unfortunately, there exist non-trivial challenges to adopting the existing solutions on HPC supercomputers for large-scale DL training applications, which include non-performance and/or failures at extreme scale, lack of portability and generality in design, complex deployment methodology, and being limited to a specific application or dataset. To address these challenges, we propose High-Velocity AI Cache (HVAC), a distributed read-cache layer that targets and fully exploits the node-local storage or near node-local storage technology. HVAC seamlessly accelerates read I/O by aggregating node-local or near node-local storage, avoiding metadata lookups and file locking while preserving portability in the application code. We deploy and evaluate HVAC on 1,024 nodes (with over 6000 NVIDIA V100 GPUS) of the Summit supercomputer. In particular, we evaluate the scalability, efficiency, accuracy, and load distribution of HVAC compared to GPFS and XFS-on-NVMe. With four different DL applications, we observe an average 25 % performance improvement atop GPFS and 9% drop against XFS-on-NVMe, which scale linearly and are considered the performance upper bound. We envision HVAC as an important caching library for upcoming HPC supercomputers such as Frontier.

includes characterizing which modules have been ported to multi-accelerator nodes, initial performance analyses, the status of software integration, and a current vision of successes, obstacles, and next steps. As such this report contains not only an accurate snapshot of each sub-project's current status, but also represents an unprecedentedly broad account of experiences porting large scientific applications to next-generation HPC architectures.

Oak Ridge National Laboratory's (ORNL's) Leadership Computing Facility (OLCF) continues to surpass its operational target goals: supporting users; delivering fast, reliable computational ecosystems; creating innovative solutions for high performance computing (HPC) needs; and managing risks, safety, and security associated with operating some of the most powerful computers in the world. The results can be seen in the cutting-edge science conducted by users and the praise from the research community. Calendar year (CY) 2019 was a big year as OLCF staff ran five world-class resources (the leadershipclass computers Titan and Summit, the large analysis cluster called Eos, and the massive parallel filesystems called Atlas and Alpine)) and also began power and cooling upgrades for a 2021 exascale system called Frontier. While continuing exceptional operation of Titan, Eos, and Rhea, the OLCF released the Summit supercomputer for production on January 1, 2019. Summit debuted as the most capable and efficient system in its class and has been recognized as the most powerful system in the world for its performance on both the high performance linpack (HPL) and conjugate gradient (HPCG) benchmark applications since June 2018 according to TOP500. Summit represents the culmination of a multiyear effort between the OLCF, IBM, NVIDIA, and Mellanox to deliver a system that is unmatched for modeling, simulation, data analysis, and learning. To hit the ground running with science-ready applications on day one, application teams worked closely with the OLCF through the Center for Accelerated Application Readiness (CAAR) program for years in advance of the Summit deployment. CY 2019 was filled with outstanding results and accomplishments: a very high rating from users on overall satisfaction for the sixth year in a row; a tremendous amount of core-hours delivered to researchers from two leadership-class systems; and success in delivering on the allocation split of roughly 60%, 30%, and 10% of core-hours offered for the Innovative and Novel Computational Impact on Theory and Experiment (INCITE), Advanced Scientific Computing Research Leadership Computing Challenge (ALCC), and Director's Discretionary (DD) programs, respectively (see Operational Performance section). These accomplishments, coupled with the high utilization rates (overall and capability usage), represent the fulfillment of the promise of both leadership-class machines: efficient facilitation of leadership-class computational applications. Table ES.1 presents a summary of the 2019 OLCF metric targets and the associated results. More information can be found in the Operational Performance section for each OLCF resource. The scientific accomplishments of OLCF users are a strong indication of long-term operational success, with publications this year in such notable journals and publications as Nature, Nature Physics, Nature Plants, Physical Review X, Journal of the American Physical Society, Cell, Nano Letters, and Trends in Biotechnology. Crucial domain-specific discoveries facilitated by resources at the OLCF are described in the High Performance Computing Facility Operational Assessment 2019 Oak Ridge Leadership Computing Facility (OAR) Strategic Results section. For example, researchers used Summit to pinpoint and understand the production of proteins from genetic information, including mutations and the functional expression of disease (Section 8.2).

The US Department of Energy deployed the Summit and Sierra supercomputers with the latest state-of-the-art network interconnect technology in 2018 and both systems entered production in 2019. In this paper, we provide an in-depth assessment of the systems' network interconnects that are based on Enhanced Data Rate (EDR) 100 Gb/s Mellanox InfiniBand. Both systems use second-generation EDR Host Channel Adapters (HCAs) and switches with several new features such as Adaptive Routing (AR), switch-based collectives, and HCA-based tag matching. Although based on the same components, Summit's network is "non-blocking" (i.e., a fully provisioned Clos network) and Sierra's network has a 2:1 taper between the racks and aggregation switches. We evaluate the two systems' interconnects using traditional communication benchmarks as well as production applications. We find that the new Adaptive Routing dramatically improves performance but the other new features still need improvement.

The I/O subsystem for the Summit supercomputer, No. 1 on the Top500 list, and its ecosystem of analysis platforms is composed of two distinct layers, namely the in-system layer and the center-wide parallel file system layer (PFS), Spider 3. The in-system layer uses node-local SSDs and provides 26.7 TB/s for reads, 9.7 TB/s for writes, and 4.6 billion IOPS to Summit. The Spider 3 PFS layer uses IBM's Spectrum Scale™ and provides 2.5 TB/s and 2.6 million IOPS to Summit and other systems. While deploying them as two distinct layers was operationally efficient, it also presented usability challenges in terms of multiple mount points and lack of transparency in data movement. To address these challenges, we have developed novel end-to-end I/O solutions for the concerted use of the two storage layers. We present the I/O subsystem architecture, the end-to-end I/O solution space, their design considerations and our deployment experience.

Burst buffers (BBs) are increasingly exploited in contemporary supercomputers to bridge the performance gap between compute and storage systems. The design of BBs, particularly the placement of these devices and the underlying network topology, impacts both performance and cost. As the cost of other components such as memory and accelerators is increasing, it is becoming more important that HPC centers provision BBs tailored to their workloads.This work contributes a provisioning system to provide accurate, multi-tenant simulations that model realistic application and storage workloads from HPC systems. The framework aids HPC centers in modeling their workloads against multiple network and BB configurations rapidly. In experiments with our framework, we provide a comparison of representative Oak Ridge Leadership Computing Facility (OLCF) I/O workloads against multiple BB designs. We analyze the impact of these designs on latency, I/O phase lengths, contention for network and storage devices, and choice of network topology.

The layout-aware data scheduling (LADS) data movement framework optimizes congestion for end-to-end data transfers. During data transfer, LADS can avoid congested storage elements by exploiting the underlying storage layout at each endpoint. This improves the I/O bandwidth and hence the data transfer rate across high-speed networks. However, the absence of fault tolerance (FT) in LADS results in data retransmission overhead and may lead to possible data integrity issues upon faults. In this paper, we propose object-logging FT mechanisms to avoid transmitting the objects that are successfully written into the parallel file system (PFS) at the sink end. Depending on the number of log files created for the whole dataset, we have classified our FT mechanisms into three different categories: file logger, transaction logger, and universal logger. Also, to address the space overhead, we have proposed different methods of populating the log files with the information of the successfully transferred objects. We have evaluated the data transfer performance and recovery time overhead of the proposed object-logging-based FT mechanisms on the LADS data transfer framework. Our experimental results show that FT mechanisms exhibit negligible overhead (< 1%) with respect to the data transfer time. However, the fault recovery time is 10% higher than the total data transfer time at any fault point.

The evergrowing trend of big data has led scientists to share and transfer the simulation and analytical data across the geodistributed research and computing facilities. However, the existing data transfer frameworks used for data sharing lack the capability to adopt the attributes of the underlying parallel file systems (PFS). LADS (Layout-Aware Data Scheduling) is an end-to-end data transfer tool optimized for terabit network using a layout-aware data scheduling via PFS. However, it does not consider the NUMA (Nonuniform Memory Access) architecture. In this paper, we propose a NUMA-aware thread and resource scheduling for optimized data transfer in terabit network. First, we propose distributed RMA buffers to reduce memory controller contention in CPU sockets and then schedule the threads based on CPU socket and NUMA nodes inside CPU socket to reduce memory access latency. We design and implement the proposed resource and thread scheduling in the existing LADS framework. Experimental results showed from 21.7% to 44% improvement with memory-level optimizations in the LADS framework as compared to the baseline without any optimization.

In 2015, OLCF's Titan supercomputer experienced a significant increase in GPU related job failures. The impact on jobs was serious and OLCF decided to replace ~50% of the GPUs. Unfortunately, jobs using more than 20% of the machine (i.e., leadership jobs) continued to encounter higher levels of application failures. These jobs contained significant amounts of both the low-failure rate and high-failure rate GPUs. The impacts of these failures are more adversely felt by leadership jobs due to longer wait times, runtimes, and higher charge rates. In this work, we have designed techniques to increase the use of low-failure GPUs in leadership jobs through targeted resource allocation. We have employed two complementary techniques, updating both the system ordering and the allocation mechanisms. Using simulation, the application of these techniques resulted in a 33% increase in low-failure GPU hours being assigned to leadership jobs. Our GPU Age-Aware Scheduling has been used in production on Titan since July of 2017.
